Switching AC DC Adapter For Led Lights , LED Tape Power Supply 15W Overload Protection
Switching AC DC Adapter For Led Lights , LED Tape Power Supply 15W Overload Protection
Switching AC DC Adapter For Led Lights , LED Tape Power Supply 15W Overload Protection
Switching AC DC Adapter For Led Lights , LED Tape Power Supply 15W Overload Protection
Specifications
Brand Name :
OEM
Model Number :
LLD-SP8A
Certification :
CE TUV EMC LVD RoHS
Place of Origin :
Changzhou
MOQ :
200PCS
Price :
Negotiable
Payment Terms :
T/T Paypal
Supply Ability :
100000PCS
Delivery Time :
15-20 working days
Packaging Details :
100PCS per Carton
Item :
Switching power supply for strip light
Model :
LLD-ADPXA
Input :
AC100-240V 50/60Hz
Output :
12VDC XA
Power :
180W
warranty :
3 years
Description

12V 1A 5A 10A 15A 20A 30A LED Strip Power Adaptor Driver Power Supply for Strip Light

Features:

Universal AC input / full range

It's good quality & high performance

Input:AC110-220V 50/60Hz

Out put: DC 12V

DC12V:1A/2A/3A/5A/10A/15A/20A/30A

100% full load burn-in test

Protections: overload/ over voltage/ short circuit

Cooling by free air convection

This Power Supply Unit "DOES NOT come with installation instruction, wiring cable, on/off switch, or screws.

How to calculate Support max LED Strip Length:

Assumption: Your LED Strip 60LEDs/m, and each LED 0.2W, then calculate max LED Strip Length: 0.2W/LED × 60LEDs/m=12W/m, 60W(this listing)÷12W/m=5m, So, Support the LED Strip(60LEDs/m, 0.2W/LED) Length (Max)=5M

Connection:

L, N: AC power input

GND: DC power output "-"

V: DC power output "+"

+V / ADJ: Adjust the output voltage

Safety Compliance: CCC/ FCC / CE

Working Temperature: 0~40

Storage Temperature: -20~60

Ambient Humidity: 0~95% Non-Condensation

Products specification

Item Output current Output voltage Input voltage Power Size Weight
1 1.25A DC12V AC85-265V 15W 7*4*3cm 60g
2 2A DC12V AC85-265V 24W 9*6*3cm 110g
3 3A DC12V AC85-265V 36W 9*6*4cm 130g
4 5A DC12V AC85-265V 60W 11*8*4cm 170g
5 10A DC12V AC85-265V 120W 13*10*4cm 340g
6 15A DC12V AC85-265V 180W 20*10*4cm 500g
7 20A DC12V AC85-265V 240W 20*11*5cm 640g
8 30A DC12V AC85-265V 360W 22*12*5cm 790g

IN-DOOR USE ONLY!
