THT 0.28 Inch height 4 digits7 Segment LED SMD Display White Red Blue Color
THT 0.28 Inch height 4 digits7 Segment LED SMD Display White Red Blue Color
Specifications
Brand Name :
Interled
Model Number :
BD4-28XXX-XX3
Certification :
RoHS
Place of Origin :
China
MOQ :
2000
Payment Terms :
T/T
Supply Ability :
500KK per month
Delivery Time :
3-4 weeks
Packaging Details :
Carton box
Color :
White, Red, Blue...
Mounting :
THT (Through-Hole Technology)
Function :
Graphics
Common pin :
Common anode/cathode
Lifetime :
50000Hrs
OEM or ODM :
Yes
Applicaiton :
Indoor
Description

Four digits, 0.28 inch digit, 7-segment diplay, common anode or common cathode.

Four digits 7 segment led display features

a, Black or grey surface with white diffuse

b, Colors: red(640nm),yellow green (572nm),pure green(525nm),yellow(590nm),blue(430nm), pure blue(470nm).

c, Digit height: 0.28"

d, Customized requirements can meet.

Products Selection Guide

Part No. Chip Electro-optical Data (At 10mA)
Common Anode Common Cathode Material/Emitted Color Wave Length λD(nm) VF (V) Iv.Typ. Per.Seg. (mcd)
Typ.
BX2-541UB-A13 BX2-521UB-C13 InGaN/SiC Blue Chip 465 3.2 15
BX2-521TB-A13 BX2-521TB-C13 InGzN/Al2O3 Blue Chip 465 3.1 18
BX2-521PG-A13 BX2-521PG-C13 InGaN/SiC Pure Green Chip 525 3.2 22
BX2-521GU-A13 BX2-521GU-C13 Gap/Gap Yellow Green Chip 570 2.15 5
BX2-521UG-A13 BX2-521UG-C13 AlGaInP/GaAs Yellow Green Chip 570 2.1 12
BX2-521HY-A13 BX2-521HY-C13 GaAsP/GaP Yellow Chip 590 2.1 3
BX2-521UY-A13 BX2-521UY-C13 AlGaInP/GaAs Yellow Chip 590 2.05 20
BX2-521YO-A13 BX2-521YO-C13 AlGaInP/GaAs Orange Chip 605 2.05 20
BX2-521HO-A13 BX2-521HO-C13 GaAsP/GaP Orange Chip 625 2 3
BX2-521UR-A13 BX2-521UR-C13 AlGaInP/GaAs Red Chip 630 1.95 15
BX2-521SR-A13 BX2-521SR-C13 AlGaAs/GaAs Red Chip 643 1.85 6

THT 0.28 Inch height 4 digits7 Segment LED SMD Display White Red Blue Color

FAQ

Q: What Types of LED do you need?

A: Leds can now be manufactured in a variety of sizes and package types. Different Lenses and diffusers can be added to the package to create a particular characteristic output from the LED. NEWSHINE could produce thus products as below, but is not limited to the following LED types:

*SMT

*Thru Hole

*Bi Color

*Tri Color

*RGB LEDs

*Infra-Red Leds

*COB Leds

*Multi Chip Devices

Q: What is RGB?

A: RGB stands for Red, Green, Blue. Each color is split into the three primary colors and three values are output from the encapsulation displays.

Q: Can you make special/customized LED display items, according to private design/prototype?

A: Yes, engineers could use your CAD/DWG engineering files directly or can help design the customized LED display panels.

Not limited to 7 segment LED display, alphanumeric led display, led dot matrix display module etc.
