Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Parking Lot High Power 4000K 80W IP66 LED Flood Light
Specifications
Brand Name :
LCD-CESP
Model Number :
LCD-HB-S3-085-LNXX
Certification :
CE RoHs SAA ETL UL TUV
Place of Origin :
SHENZHEN, CHINA
MOQ :
1pcs
Price :
usd
Supply Ability :
5000pcs/ month
Delivery Time :
5-12 work day
Packaging Details :
Carton box
Led light source :
SMD 5050
Frequency Range :
50-60HZ
Power Factor :
>0.95
Power Efficiency :
>90%
Total Power :
50W 80W 100W 150W 200W
Lamp luminous flux(lm) :
7,750 lumen to 31,000 lumen
Description

Parking Lot High Power 12000 Lumen 80W IP66 LED Flood Light

Die cast Aluminum alloy housing 12000 lumen waterproof IP66 LED Flood Light 80W

Product family details

Ambient Temperature
  • -30 to +45 °C
Main color of the Luminaire
  • Dark gray
Beam spread luminaire
  • 30° 60° 60° 60° 100° 120°
Initial correlated color temperature
  • 4000K, 5000K, 6500K
Luminous Efficiency
  • 140LM per watt
Input frequency
  • 50 to 60 Hz
Input voltage
  • 220-240 V
Light source color
  • 840 neutral white, 865 cool daylight
Material
  • Housing: aluminum die-cast
  • Cover: polycarbonate, flat
Median Useful Life L70B50
  • 50000 h

Looking for a low cost LED high bay?

Well here it is! The HB-S3 is one of the brightest lights on the market today. Competitors offer similar fixtures.

Model LCD-HB-S3-055 LCD-HB-S3-085 LCD-HB-S3-105 LCD-HB-S3-125 LCD-HB-S3-155 LCD-HB-S3-205
Lumens 7,500 lm 12,000 lm 15,000 lm 18,000 lm 22,500 lm 30,000 lm
Power 50W 80W 100W 120W 150W 200W
Comparable HID or Metal Halide 150W 250W 350W 400W 500W 650W

Parking Lot High Power 4000K 80W IP66 LED Flood Light

Applications
・Container/ terminal lighting (High-mast lights)
・Apron floodlighting for Airport
・Car park (High-mast lights)

Parking Lot High Power 4000K 80W IP66 LED Flood Light

Parking Lot High Power 4000K 80W IP66 LED Flood Light

Parking Lot High Power 4000K 80W IP66 LED Flood Light

HB Family

TyPE LCD-HB-S3-055-LNXX LCD-HB-S3-085-LNXX LCD-HB-S3-105-LNXX LCD-HB-S3-125-LNXX LCD-HB-S3-155-LNXX LCD-HB-S3-205-LNXX
Luminous Flux 7,500 lm 12,000 lm 15,000 lm 18,000 lm 22,500 lm 30,000 lm
Lens 30º narrow 30º narrow 30º narrow 30º narrow 30º narrow 30º narrow
Power consumption 50W 80W 100W 120W 150W 200W
Color Temperature 3000K 4000K 6500K 3000K 4000K 6500K
Color Rendering Ra>75 Ra>75 Ra>75 Ra>75 Ra>75 Ra>75
Input Voltage AC100-277V AC100-277V AC100-277V AC100-277V AC100-277V AC100-277V
Frequency 50-60 Hz 50-60 Hz 50-60 Hz 50-60 Hz 50-60 Hz 50-60 Hz
Main Body Aluminum Alloy Aluminum Alloy Aluminum Alloy Aluminum Alloy Aluminum Alloy Aluminum Alloy
Outer lens PC with Anti-UV & Hard-coating PC with Anti-UV & Hard-coating PC with Anti-UV & Hard-coating PC with Anti-UV & Hard-coating PC with Anti-UV & Hard-coating PC with Anti-UV & Hard-coating
Exterior Painting Heavy-duty salt resistant paint Heavy-duty salt resistant paint Heavy-duty salt resistant paint Heavy-duty salt resistant paint Heavy-duty salt resistant paint Heavy-duty salt resistant paint
Mount Type Adjustable bracket & eye bolt Adjustable bracket & eye bolt Adjustable bracket & eye bolt Adjustable bracket & eye bolt Adjustable bracket & eye bolt Adjustable bracket & eye bolt
Operating Temperature -30º--+50° -30º--+50° -30º--+50° -30º--+50° -30º--+50° -30º--+50°
Rated Life (L70) 50,000h 50,000h 50,000h 50,000h 50,000h 50,000h
IK rate IK09 IK09 IK09 IK09 IK09 IK09
Surge protection 2-4Kv(normal mode) 10KV(on requests) 2-4Kv(normal mode) 10KV(on requests) 2-4Kv(normal mode) 10KV(on requests) 2-4Kv(normal mode) 10KV(on requests) 2-4Kv(normal mode) 10KV(on requests) 2-4Kv(normal mode) 10KV(on requests)

LIGHTING PERFORMANCES

Parking Lot High Power 4000K 80W IP66 LED Flood Light

Product dimension

Parking Lot High Power 4000K 80W IP66 LED Flood Light

Installation

Parking Lot High Power 4000K 80W IP66 LED Flood Light

Packing data

Parking Lot High Power 4000K 80W IP66 LED Flood Light
