4mm Thick Temper Glass IP65 Industrial LED Flood Lights

4mm thick temper glass IP65/IK08 rated 140lm/w 120W Industrial LED Flood Light

light distribution
The light distribution of the FT-series is generated by a structured reflector. With a reflectivity of nearly 97% it is possible to use almost the whole luminous flux and the whole lamp efficiency gets better. By using an optional available diffuse cover it is possible to illuminate outdoor areas which demand high requirements in glare limitation. The photometrical files of these luminaires can be email by our salespersons.

light source
To get a relieable and efficient light source we have chosen a diode from the well known company CREE , LUMILEDs , Bridgelux or OSRAM.
The for years used diode has even at high temperatures a small loss of luminous flux und extremly good photometric characteristics, for example a high color rendering index.

​

Key Features

1. The light source adopts high lumen output and high quality LEDs chip LUMILEDs SMD3030 or OSRAM SMD3030 .
2. The heat fin in extruded aluminum AL6063-T5 (heat conductivity 201W/m*K and 2.1 twice mor than popular die cast aluminum alloy ADC12 conductivity 96W/m*K),ensures the efficiency of heat emission, guaranteeing the light a long life span.
3. The high quality pure polish aluminum as the reflector has high reflecting efficiency, and it can make sure the luminous flux, controlling the light inside of a useful area. It improves the efficiency of light uniformity and utilization, showing the LED advantage of energy saving.
4. The integration of 4mm high strength roughened temper glass and the housing makes the light work perfectly in the high humidity environments.
5. New high efficiency constant current driver Meanwell or Philips brand. Wide range of input voltage: AC100-277V or 200-240VAC.
6. No delay start. No waiting. It can reach its normal light as soon as it is turned on. No noise.
7. No electrical wave, compliance to CE RoHs SAA TUV.
8. Environment friendly and no lighting pollution. We exert the design of using cold light source. It’s no heat radiation. The floodlights do not have lead, hydrargyrum and any other contamination. It is really environment friendly with ROHS certificate

Technical data

Model	Power(W)	Current(A@230VAC)	IP-protection	Dimensions(mm)	Weight(KG)
LCD-FT-013	10	0.045	IP65 / IK08	185x135x68	0.75
LCD-FT-023	20	0.091	IP65 / IK08	185x135x68	0.85
LCD-FT-033	30	0.137	IP65 / IK08	220x180x88	1.30
LCD-FT-053	50	0.228	IP65 / IK08	220x180x88	1.50
LCD-FT-073	70	0.320	IP65 / IK08	260x195x105	1.80
LCD-FT-103	100	0.460	IP65 / IK08	305x250x125	4.80
LCD-FT-123	120	0.550	IP65 / IK08	305x250x125	5.00
LCD-FT-153	150	0.690	IP65 / IK08	305x250x125	5.30
LCD-FT-203	200	0.910	IP65 / IK08	400x360x140	8.10

illumination distribution
Product dimension

installation

1. Carefully take the product out of the packaging removing any transport safeguards.

2. The product is solely suited for installation on the wall, ceiling and floor.

3. This product must be installed by a preofessional electrician.

4. Please make sure that the thermal management can work without problem. Take a look at picture below.

5. Fasten the fixture to the installation place using properly dimensioned fastening materials.

6. Connect the floodlight with a power source.

7. Check if the product functions properly and if it is securely fixed

8. The product is now ready for operation.

Wall mounted	Surface mounted	Ceiling mounted

III. warning
The installation should only be done by a professional electrician!
Warranty for this product is 5 years.
The warranty expires by abnormal usage, connection or change of the structure. Damage by high voltage is not covered by the warranty: >4kV(L,N to PE) / 2kV(L to N)
For more technical information, please contact our customer support!

Product exploded view
