Long Lifespan IP67 Stainless Steel Marine Grade Floodlights

led marine flood lights 50 watt 230V 50/60Hz 145lm/w IP67 stainless steel body

Over View

This series of LED flood lights have wide power options from 50W upto 400W. It adopts aluminum alloy heat sink to maintain a low working temperature, and provide long life of the luminaire. It adopts >130lm/W CREE light source and high standard waterproof LED driver for a long operation life. The individual modular design creates high flexibility for the optical lenses and power range options.

Product
Power	50W +/-10%
Luminous flux	6500-7250lm +/-10%
CRI	≥75
Calculated Lumen Maintenance	＞100000hours
Color Temperature	3000/4000/6500K
	lens optional Symmetrical PC lens:20/40/60/60/90˚ Asymmetrical PC lens:100*140˚
	1060 Aluminum Commercially pure aluminum, high aluminum content and purity, high corrosion resistance and high thermal conductivity. Outstanding performance, with excellent thermal conduction effect that general aluminum alloy can not be.
LED quantity	60pcs x 1module / 25pcs x 1 module
Input Voltage	100-277 VAC
Driver	Meanwell & Philips driver
THD	＜20%
Power Factor	＞95%
Power-supply Efficiency	＞90%
Weight	4.0kg
Lens	Polycarbonate
Fixation material bracket	stainless Steel#316
Waterproof	IP66
Protection class IEC	Safety class I (I)
Corrosion-proof grade	Marine grade
Operating Temperature	-35℃-+55℃
Humidity	10-90% RH
Surge Protection	4KV
Dimension	340*125*176mm
Maximum Exposed Surface	0.0425㎡

Key Points:

Long lifespan: 110.000Hr and free maintenance.

High lumen: 130lm/watt to offer a bright world and protect eyes.

Energy saving: 60% compare to traditional ML and HID Lights

Power saving and Maintaining:

Photometric:

Test

Application

FAQ

1. What 's your payment method?

In general, we use Paypal and Western Union for the total order less than US$ 500 in order to reduce the extra fee, Bank Tranfer payment can be accepted for large order too.

2. How long will it take to execute my order ?

This depends on the order quantity.Our nornal delivery time is 5-7 working days.

3. How much will the shipping charges be ?

This will depend on the size of your shipment and the method of shipping. Whe inquiriedabout shipping charges, we hope that you let us know the detailed information such as the post code and quantity, your favorable method of shipping (by air or by sea ) and your designated port or airport.

4. Do you provide samples ?

Yes, we can provide samples of all the items listed.In general of facture rule, the sample cost and shipping cost will be in buyer side. We can send the sample by DHL, FEDEX, EMS and UPS .

5. Do you have products in stock?

For most common items we have stock but we could not reserve all the items in stock. If there is any in stock, we will inform you with details.

6. What the warranty term for your products?

All of our products have at least one year warranty in normal use. Please provide or video ia any quality problem during this period.We will replace a new one to you in thenext order.

7. Can I visit you?

Sure, please let us know if you wanna visit our factory, we will arrange it for you.

8. Do I need to send the defective products back to you for warranty.

No, you don’t need to send it back for warranty for the defective products. If any damage happens not caused by misure or vandalism, then we ‘ll send you a new one.
