Specifications
Brand Name :
DUALRAYS
Model Number :
DR-SPL400-FGXP
Certification :
CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Place of Origin :
Shenzhen,China
MOQ :
1pcs
Price :
Negotiable
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000PCS/Month
Delivery Time :
5-15 Bussiness Day
Packaging Details :
Netural Package/OEM and ODM Package Available
Rated Power :
400W
Lumen Maintenance @ 6000 hrs :
>90%
Warranty :
5 years
Material :
Aluminium Alloy 6063+PC
Applications :
Sports ground/Exterior square, garden...
Installation methods :
Suspended/Surface Mounted/Adjustable Installation For Option
Description

High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground

High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China
High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China

Options:

> Surge Protection Device: Meanwell SPD-20 20KV Surge Protector;

> Lens : Symmetrical 30°/60°/90° beam angle optional;

> Aiming Device: Laser Pointer;

> Driver: Meanwell ELG/HLG driver;

> Controls and Dimming: 1-10V, DALI,PWM,Zigbee for Option;


High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China

Model No. DR-SPL300-FGXP DR-SPL400-FGXP DR-SPL600-FGXP DR-SPL800-FGXP
System Watts/W 300W 400W 600W 800W
System Efficiency/LPW 150LPW
Lumen Output/lm 45.000±5% 60.000±5% 90.000±5% 120.000±5%
Rated Input Voltage/V AC100~277V, 50/60Hz
LEDs Light Source SMD5050
SDCM <5
CCT/K 5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra >70Ra (>80Ra for Option)
Power Factor >0.95
THD <10%
Beam Angle(Optional) 30°/60°/90°
UGR <25
Surge Protection 4~6KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver Meanwell ELG / HLG Optional
IP Rating IP65
Dimming(Optional) 1-10V, DALI,PWM,Zigbee for Option
Safety Protection Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Start Time 0.5s
Protection Class ClassⅠ
Finishing Color(Optional) Black RAL9017(Standard) / White RAL9016 Optional
Material Aluminum+PC
Lifespan/hrs 70.000 Hrs (Ta=30℃@L70)
Operation Temp/℃ 40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃ - 40°C to + 65°C(-40°F to 149°F)
Switching Cycles 100,000 Times
Certificate CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available
Aiming device Laser positioner
Equivalent 1000W MHL
Dimming Function 1-10VDC /DALI
Intelligent controlling Zigbee
Material AL+PC
TM21 L80>50000hrs
Life span 5 years
High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China
Character/Power
300W
400W
600W
800W
High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From ChinaHigh Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China
A / mm
Ø445
Ø445
Ø537
Ø537
B / mm
321
321
373
373
High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China
High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China

High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China
High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China
High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China

High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China
High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China

High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China

High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China

High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China

Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-SPL300-FGXP
12.4
610*510*250
13.8
1PCS/CTN
DR-SPL400-FGXP
12.9
610*510*250
14.7
1PCS/CTN
DR-SPL600-FGXP
25.3
890*710*275
27.6
 1PCS/CTN
DR-SPL800-FGXP 25.9 890*710*275 28.8
1PCS/CTN


High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China
High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China

High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China


High Power LED Flood Light 400W Adjustable Bracket For Exterior Sports Ground Led Light Importer From China
