600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
Specifications
Brand Name :
DUALRAYS
Model Number :
DR-FL600-DGXP
Certification :
CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Place of Origin :
Shenzhen,China
MOQ :
2PCS
Price :
Negotiated
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
5-15 Bussiness Day
Packaging Details :
Netural Package/OEM and ODM Package Available
Supply Ability :
30000PCS/Month
Rated Wattage :
600W
Model No. :
DR-SPL600-FGXP
Warranty :
5 years
Driving Brand :
Meanwell
IP Rating :
IP66
CRI :
>83
Description

600W LED Flood Light Full Al Heat Sink Structure For Large And Small Parking / Square

600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
> High Brightness LUMILEDS LUXEON SMD5050 LEDs, Meanwell HLG / ELG Driver Optional;
> Precision Integrated Die-casting Process,Excellent Thermal Conductivity；
> IP65 / IK08 Protection;
> Symmetrical 30°/60°/90° beam angle optional;
> Corrosive Resistant Powder Coated Finish；
> Multi-scale lens to create well-balanced distribution and reduce glare;
> Shield to Reduce the Light Glare;
> Laser Pointer to Assistant Installation for the Best Lamp Position Angle to Get a Optimal Light Distribution;
> 360°Adjustable Supporting Fixture;
> No UV or IR and completely mercury free;
> L70/B20 @ 70.000h;
> Customized supported for special projects;
* TM21(L80>50000hrs);

600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
Model No.
 DR-SPL300-FGXP DR-SPL400-FGXP DR-SPL600-FGXP DR-SPL800-FGXP
System Watts/W
 300W 400W 600W 800W
System Efficiency/LPW
 150LPW
Lumen Output/lm
 45.000±5% 60.000±5% 90.000±5% 120.000±5%
Rated Input Voltage/V
 AC100~277V, 50/60Hz
LEDs Light Source
 SMD5050
SDCM
 <5
CCT/K
 5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra
 >70Ra (>80Ra for Option)
Power Factor
 >0.95
THD
 <10%
Beam Angle(Optional)
 30°/60°/90°
UGR
 <25
Surge Protection
 4~6KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver
 Meanwell ELG / HLG Optional
IP Rating
 IP65
Dimming(Optional)
 1-10V, DALI,PWM,Zigbee for Option
Safety Protection Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Start Time 0.5s
Protection Class
 ClassⅠ
Finishing Color(Optional)
 Black RAL9017(Standard) / White RAL9016 Optional
Material
 Aluminum+PC
Lifespan/hrs
 70.000 Hrs (Ta=30℃@L70)
Operation Temp/℃
 40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃
 - 40°C to + 65°C(-40°F to 149°F)
Switching Cycles 100,000 Times
Certificate
 CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
Character/Power
300W
400W
600W
800W
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
A / mm
Ø445
Ø445
Ø537
Ø537
B / mm
321
321
373
373
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens

600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens

600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens

600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens

600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens

600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens

Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-SPL300-FGXP
12.4
610*510*250
13.8
1PCS/CTN
DR-SPL400-FGXP
12.9
610*510*250
14.7
1PCS/CTN
DR-SPL600-FGXP
25.3
890*710*275
27.6
 1PCS/CTN
DR-SPL800-FGXP 25.9 890*710*275 28.8
1PCS/CTN


600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens

600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens


600W LED Sport Lighting Full Al Heat Sink Structure For Sports Stadium Field With Laser Pens
