Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Specifications
Brand Name :
DUALRAYS
Model Number :
DR-FL1200-EG1
Certification :
CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Place of Origin :
Shenzhen,China
MOQ :
1pcs
Price :
negotiable
Delivery Time :
5-15 Bussiness Day
Packaging Details :
Netural Package/OEM and ODM Package Available
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000PCS/Month
Rated Input Voltage/V :
AC100~277V, 50/60Hz
IP Grade :
IP66
PF :
>0.96
Driver :
Meanwell/SoSen
CRI :
>80Ra
Installation :
Bracket
LEDs Light Source :
SMD5050
CCT/K :
5000K for Standard (3000K/4000K/5700K/6500K Optional)
Beam Angle(Optional) :
20°/40°/60°/90°/140*60° Optional
Description

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Options:
> Driver: Meanwell ELG/HLG driver;
> Controls and Dimming: 1-10V, DALI,PWM,Zigbee;
> Surge Protection Device: Meanwell SPD-20 20KV Surge Protector;
> Lens : Symmetrical 25°/40°/50°/90°;
> Efficiency : 130~140LPW,150~160LPW
> Aiming Device: Laser Pointer;
> Light Glare: Shield;

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
> Multiple and multipurpose sports facilities and arenas
> Stadiums and Racing tracks
> Public squares
> Outdoor arenas
> Indoor sports arenas and halls

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Model No.
 DR-SPL300-DGXX DR-SPL600-DGXX DR-SPL900-DGXX DR-SPL1200-DGXX DR-SPL1500-DGXX DR-SPL1800-DGXX
System Watts/W
 300W 600W 900W 1200W 1500W
1800W
System Efficiency/LPW
 130~140LPW / 150~160LPW Optional
Lumen Output (Max) /lm
 48.000±5% 96.000±5% 144.000±5% 192.000±5% 240.000±5% 288.000±5%
Rated Input Voltage/V
 AC200~240V, 50/60Hz
LEDs Light Source
 SMD3030 / SMD5050
SDCM
 <5
CCT/K
 5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra
 >70Ra (>80Ra for Option)
Power Factor
 >0.95
THD
 <10%
Beam Angle(Optional)
 Symmetrical 25°/40°/50°/90° beam angle optional
UGR
 <25
Surge Protection
 4~6KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver
 Meanwell ELG/HLG
IP Rating
 IP65
Dimming(Optional)
 1-10V, DALI,PWM,Zigbee
Safety Protection Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Start Time 0.5s
Protection Class
 ClassⅠ
Finishing Color(Optional)
 Black RAL9017(Standard) / White RAL9016 Optional
Material
 Aluminum+PC
Lifespan/hrs
 70.000 Hrs (Ta=30℃@L70)
Operation Temp/℃
 40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃
 - 40°C to + 65°C(-40°F to 149°F)
Switching Cycles 100,000 Times
Certificate
 CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-SPL300-DGXX
8.5
585*315*260
9.7
1PCS/CTN
DR-SPL600-DGXX
17.4
625*620*260
18.8
1PCS/CTN
DR-SPL900-DGXX
26.1
625*820*260
28.2
1PCS/CTN
DR-SPL1200-DGXX
34.2
625*1150*260
36.5
1PCS/CTN
DR-SPL1500-DGXX
39.3
790*1240*260
42.5
1PCS/CTN
DR-SPL1800-DGXX
42.1
790*1240*260
46.3
1PCS/CTN

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

In addition,we can provide our customers value added service with Dialux software for lighting design projects free of charge.
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050 Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050

(DIALUX Simulation)
　　Dualrays adheres to independent innovation, Dualraysers try to build a world well-known LED industrial Lighting Brand.　　
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
(Partnership)
Ip66 1500W High Mast LED Flood Lights Salt Mist Resitant SAA,RCM CE ROHS SMD5050
