Specifications
Brand Name :
DUALRAYS
Model Number :
DR-SPL900-EGX
Certification :
CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Place of Origin :
Shenzhen,China
MOQ :
1pcs
Price :
negotiable
Delivery Time :
5-15 Bussiness Day
Packaging Details :
Netural Package/OEM and ODM Package Available
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000PCS/Month
Rated Wattage :
900W
Flux :
135000lm
Installation :
Bracket
Cover :
PC
L70 :
>65000Hrs
Housing :
Die-Casting Al
LED Light Source :
SMD5050
130~140LPW / 150~160LPW Optional :
130~140LPW / 150~160LPW Optional
LED driver :
Meanwell ELG / HLG Optional
Dimming(Optional) :
1-10V, DALI,PWM,Zigbee for Option
Description
Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Options:
> Driver: Meanwell ELG/HLG driver;
> Controls and Dimming: 1-10V, DALI,PWM,Zigbee;
> Surge Protection Device: Meanwell SPD-20 20KV Surge Protector;
> Lens : Symmetrical 25°/40°/50°/90°;
> Aiming Device: Laser Pointer;
> Light Glare: Shield;

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use
> Logistics areas (Ports)
> Stadiums and Racing tracks
> Public squares
> Apron lighting (Airports), Parking and Industrial areas
> Recreational sports lighting applications (Football, Hockey, Basketball, Golf,Tennis, etc)


Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Model No. DR-SPL300-DGXX DR-SPL600-DGXX DR-SPL900-DGXX DR-SPL1200-DGXX DR-SPL1500-DGXX DR-SPL1800-DGXX
System Watts/W 300W 600W 900W 1200W 1500W
1800W
System Efficiency/LPW 130~140LPW / 150~160LPW Optional
Lumen Output (Max) /lm 48.000±5% 96.000±5% 144.000±5% 192.000±5% 240.000±5% 288.000±5%
Rated Input Voltage/V AC200~240V, 50/60Hz
LEDs Light Source SMD3030 / SMD5050 Optional
SDCM <5
CCT/K 5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra >70Ra (>80Ra for Option)
Power Factor >0.95
THD <10%
Beam Angle(Optional) Symmetrical 25°/40°/50°/90° beam angle optional
UGR <25
Surge Protection 4~6KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver Meanwell ELG/HLG
IP Rating IP65
Dimming(Optional) 1-10V, DALI,PWM,Zigbee
Safety Protection Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Start Time 0.5s
Protection Class ClassⅠ
Finishing Color(Optional) Black RAL9017(Standard) / White RAL9016 Optional
Material Aluminum+PC
Lifespan/hrs 70.000 Hrs (Ta=30℃@L70)
Operation Temp/℃ 40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃ - 40°C to + 65°C(-40°F to 149°F)
Switching Cycles 100,000 Times
Certificate CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available


Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use
Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use
Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use



Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

1. Figure 1 shows the bolt pattern of the mount.
2.Secure the fixture using the 2 mounting
holes.
3.Connect the dimming wires.
4.Adjust the lamp angle to what you need.
Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use
Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use
Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use
Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use
Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use
Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

In addition,we can provide our customers value added service with Dialux software for lighting design projects free of charge.
Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use Highmast light led sports floodlights With Lumileds 3030 Led Chips for industrial use

(DIALUX Simulation)
　　Dualrays adheres to independent innovation, Dualraysers try to build a world well-known LED industrial Lighting Brand.　
