400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
Specifications
Brand Name :
DUALRAYS
Model Number :
DR-SPL400-FGXP
Certification :
CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Place of Origin :
Shenzhen,China
MOQ :
20pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000PCS/Month
Delivery Time :
5-15 Bussiness Day
Packaging Details :
Netural Package/OEM and ODM Package Available
Price :
Negotiated
Power :
400W
Lumen :
60,000±5%LM
Material :
Aluminium Alloy
CCT :
3000/4000/5700/6500K±200K
CRI :
>83
Power Factor :
0.95
IP Rating :
IP66
Power Efficiency :
92%
Beam angle :
15°,30°，45°，60°，90°，30*70°，80*140°，for option
Warranty :
5 Years
Description

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

> High Brightness LUMILEDS LUXEON SMD5050 LEDs, Meanwell HLG / ELG Driver Optional;
> Precision Integrated Die-casting Process,Excellent Thermal Conductivity；
> IP65 / IK08 Protection;
> Symmetrical 30°/60°/90° beam angle optional;
> Corrosive Resistant Powder Coated Finish；
> Multi-scale lens to create well-balanced distribution and reduce glare;
> Shield to Reduce the Light Glare;

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
> Multiple and multipurpose sports facilities and arenas
> Stadiums and Racing tracks
> Public squares
> Outdoor arenas
> Indoor sports arenas and halls

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
Model No.
 DR-SPL300-FGXP DR-SPL400-FGXP DR-SPL600-FGXP DR-SPL800-FGXP
System Watts/W
 300W 400W 600W 800W
System Efficiency/LPW
 150LPW
Lumen Output/lm
 45.000±5% 60.000±5% 90.000±5% 120.000±5%
Rated Input Voltage/V
 AC100~277V, 50/60Hz
LEDs Light Source
 SMD5050
SDCM
 <5
CCT/K
 5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra
 >70Ra (>80Ra for Option)
Power Factor
 >0.95
THD
 <10%
Beam Angle(Optional)
 30°/60°/90°
UGR
 <25
Surge Protection
 4~6KV SPD built in Driver,Exterior SPD 20KV Meanwell Optional
LED Driver
 Meanwell ELG / HLG Optional
IP Rating
 IP65
Dimming(Optional)
 1-10V, DALI,PWM,Zigbee for Option
Safety Protection Open Circuit / Short Circuit / Over-voltage / Over Temperature Protection
Start Time 0.5s
Protection Class
 ClassⅠ
Finishing Color(Optional)
 Black RAL9017(Standard) / White RAL9016 Optional
Material
 Aluminum+PC
Lifespan/hrs
 70.000 Hrs (Ta=30℃@L70)
Operation Temp/℃
 40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃
 - 40°C to + 65°C(-40°F to 149°F)
Switching Cycles 100,000 Times
Certificate
 CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
Character/Power
300W
400W
600W
800W
400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
A / mm
Ø445
Ø445
Ø537
Ø537
B / mm
321
321
373
373

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-SPL300-FGXP
12.4
610*510*250
13.8
1PCS/CTN
DR-SPL400-FGXP
12.9
610*510*250
14.7
1PCS/CTN
DR-SPL600-FGXP
25.3
890*710*275
27.6
 1PCS/CTN
DR-SPL800-FGXP 25.9 890*710*275 28.8
1PCS/CTN

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert
400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert


400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

Q1: What is the warranty for the F4 LED Flood Light?
RE: For the F4 Series LED flood light, Dualrays provide 5 years warranty. If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

Q2: What is colour temperature?
RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
the warmer the light given by the LED:
Warm white = 3000±200K
Natural white = 4000±200K
Pure white = 5000±200K
Cool white = 5700±200K
Q3: Is there a MOQ?
RE: 2PCS

Q4: What is the Lead time?

RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.

Q5: Can you do DIAlux Simulation?
RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

Q6: Do you offer mounting accessories?

RE: Yes, please contact us for details.

400W IP66 LED Sports Ground Floodlights 5 Years Warranty CE RoHS Cert

Jimmy Chan
Sales Engineer
Email: sales07@dualrays.com
Mobile/ Whatsapp:0086-176-8897-6690
Wechat: lg859299245
Zip Code: 518125
Add: 6th Floor,Building 10, Gangzai Industrial Park, Furong Industrial Park,Xinqiao Industrial District,Shajing,Bao‘an District,Shenzhen 518125, P.R.China
