Specifications
Brand Name :
Dualrays
Model Number :
DR-ST180-DGX
Certification :
CE,RoHS,TUV/GS,LM79,LM80
Place of Origin :
Shenzhen,China
MOQ :
1PC
Price :
Please contact us for details.
Payment Terms :
L/C, T/T, Western Union, Paypal
Delivery Time :
50000PCS/Month
Packaging Details :
Netural Package,color box package,1PCS/CTN,590(L)*380(W)*200(H)mm
Input Voltage :
AC95V-277V
Power Effciency :
95%
Power Factor :
0.95
Junction Temperature :
<80℃
CRI :
>70Ra
Warranty :
5 Years
LED's Brand :
LUXEON
Material :
Aluminium Alloy
IP Rating :
IP66
Life Span :
50,000 Hours
Description

180W High Power Outdoor LED Street Lights S4 Series With 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Outdoor LED Street Light--Details:
> Excellent heat dissipation with Die-casting Al ;
> Surge Protection: 6~10KV SPD built in driver, Exterior SPD 10KV (PHILPS) OR 20KV Meanwell Optional;
> IP66 and IK10 for outfoor street lighting application;
> Power factor>95%;
> Class I Protection;
> Driver and housing separated by spacers;
> ±10°/-90°(<90W) or ±15°/-90°(>90W) lamp head adjustable;
> No UV or IR and completely mercury free;
> L80/B10 @ 50.000h;
> CE,RoHS listed,5 years’ warranty;
> Adopting SMD3030 LEDs light source, high output lighting efficiency 140lm/W, high Color Rendering Index (CRI>70/80Ra)
Outdoor LED Street Light--Options:
> Driver: Meanwell ELG/HLG, Sosen;
> Controls and Dimming: 1-10V, DALI, PWM,Zigbee Wireless Dimming for option;
> 10KA SPD,20KA Meanwell SPD optional;
> Black RAL9017/ White RAL9016
> 3-pins photocell controller ON/OFF,and 7-pins LORA/NEMA socket smart wireless control available;
> Zigbee module (Single-lamp Controller and centralized manager) with software for option;
> DALI driver and DALI Centralized Manager optional;
> Light pole adapter for different poles optional;
> Customized supported for special projects;
> Surge Protection: 6~10KV SPD built in dirver, Exterior SPD 10KV (PHILPS) OR 20KV Meanwell Optional
Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket
* Roadways.
* Avenues.
* Walkways.
* Loading Area.
* Parking lot.
* Playground.
* Sport and Stadium.


Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Model No. DR-ST180-DGX
Rated Power/W 180W
Systen Efficiency/LPW 150LPW
Lumen Output/ Im 27.000+5%
Rated Input Voltage/V AC100~277V 50/60Hz
SDCM <6
CCT/K 3000K/4000K/5000K/5700K/6500K
Color Index 70Ra (>80Ra for Option)
Power Factor >0.95
THD <10%
Beam Angle (Optional) Type I/ Type II (Long and medium)/ Type III (Medium)/Type IV (Medium)/Type V (Medium)
UGR <25
Surge Protection 6~10KV SPD built in driver, Exterior SPD 10KV (PHILPS) OR 20KV Meanwell Optional
Dimming options 0/1-10V/PWM/DALI/Zigbee
Protection Class Class I
Finishing Color (Optional) Black RAL9017/ White RAL9016
Material Aluminum+PC+Toughened Glass
Pipe Diameter ø60mm
Certificate CE,ROHS,TUV/GS,LM79,LM80

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket
30W/60W Version
Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket
90W,120W/150W/180W Version
Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket
Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket
Packaging Information
Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket
Shipment
Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket
Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!

Dualrays 180W S4 Series High Power Outdoor LED Street Lights with 60mm Diameter Bracket
Marketing Department
Tel: 0086-755-2306 6948
Fax: 0086-755-6164 1072
Vera Fu
Sales manager
Email: sales06@dualrays.com
Mobile/ Whatsapp:0086-13018674100
Wechat: fuwei950615
Zip Code: 518103
Add: 3rd Floor,Building A3 | Tianrui Industrial Park| #35,Fuyuan 1st Road,Fuyong Town,Bao'an Dist | Shenzhen 518103
