Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Specifications
Brand Name :
DUALRAYS
Model Number :
DR-TPL030-EG31
Certification :
CE,ROHS,TUV/GS,LM79,LM80
Place of Origin :
CHINA
MOQ :
6pcs
Price :
Please inquiry for latest price
Payment Terms :
L/C, T/T, Western Union,Paypal
Supply Ability :
100000pcs/month
Delivery Time :
5-15 bussiness days
Packaging Details :
Netural Package,color box package,6PCS/CTN,L955xW200xH270mm
Warranty :
5 years
Efficiency :
160lm/w
IP Rating :
IP65
LEDs brand :
Epistar
Material :
AL+PC
LED Source :
SDM2835
Description
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
D5 Series LED Tri Proof Light--Data Sheet
Rated Power: 30W LEDs Typ/Qty: SMD2835 240pcs
Luminous Flux: 4,800±5% AC Input Vol: AC100~277V 50/60Hz
Power Factor: PF>0.9 Lumen Maintenance @ 6000 Hrs: >90%
Switching Cycle Before Failure: 100,000 Power Supply: Boke
D5 Series LED Tri Proof Light--Features
> Highly brightness EPISTAR/SAN‘AN SMD2835 LEDs,energy efficient - up to 160 lm/w;
> 1-10V dimming flicker-free driver,DIP Switch Power Adjustment available,CCT adjustable available;
> Single or Double wiring;
> IP65/IP66 and IK10 for all industrial areas of application;
> Buckle Design End-cap,quick & convenient to open and relock for wiring,greatly improve efficiency and save labor cost;;
> Multiple Link with double wiring;
> No UV or IR and completely mercury free;
> L80/B10 @ 50.000h;
> 5 years warranty;

D5 Series LED Tri Proof Light--Features
> Driver: DUALRAYS Own-developed flicker-free driver,BOKE DIP switch power adjustable driver.
> Controls and Dimming: Zigbee wireless control / 1-10V Dimming / Daylight sensor,microwave sensor,CCTadjustable,emergency.
> Plug : European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable optional.
> Installation: Suspension, Ceilign Mounted and adjustable surface mount.
> Single or double wiring and connection.
> Customized supported for special projects.
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
* Replacement for fluorescent NCF
* Workshops and warehouse
* Garage and car parks
* Sport facility
* Corridor/Gallery/Corridor
* Outdoor & Indoor Locations

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Character/Length
2ft
3ft
4ft
5ft
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
A
600mm
900mm
1200mm
1500mm
B
90mm
90mm
90mm
90mm
C
74mm
74mm
74mm
74mm

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
DALI Device
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

DALI Intelligent Control Diagram
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10 Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

DALI Intelligent Control Operator Interface
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Packaging Information
Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!

Dualrays D5 Series 30W SMD2835 Led Tri Proof Light 3ft BOKE Driver IP66 IK10

Marketing Department
Tel: 0086-755-2306 6948
Fax: 0086-755-6164 1072
Vera Fu
Sales Engineer
Email: sales06@dualrays.com
Mobile/ Whatsapp:0086-13018674100
Wechat: fuwei950615
Zip Code: 518103
Add: 3rd Floor,Building A3 | Tianrui Industrial Park| #35,Fuyuan 1st Road,Fuyong Town,Bao'an Dist | Shenzhen 518103
