150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
Specifications
Brand Name :
DUALRAYS(OEM available)
Model Number :
DR-ST150-DGX
Certification :
CE, ROHS, TUV/GS, LM79, LM80
Place of Origin :
Shenzhen, China
MOQ :
1PCS
Price :
Please inquiry for latest price
Payment Terms :
L/C, T/T, Western Union, paypal
Supply Ability :
50000PCS/Month
Delivery Time :
5-15 bussiness days
Packaging Details :
Netural Package/OEM and ODM Package Available
Input Voltage :
AC100-277V 50/60Hz
CCT :
WW:3000±200K NW: 4000±200K DW:5000±200K CW: 5700±200K
Dimming Function :
1-10VDC /PWM / Resistance
LED Source :
LUMILEDS LUXEON
UGR :
<25
Power factor :
0.95
CRI :
>70Ra/>80Ra
Power :
30W/60W/90W/120W/150W/180W
Efficiency :
150LPW
Guarantee :
5 years
Description

Dualrays S4 Series 30W-180W Intelligent LED Street Light 140LPW efficiency IP66 IK08 5 years guarantee

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
> Well-known brand of driver and LEDs, support stable working and long life of the luminair;
> Strong Al housing, fluent streamline outlook, provide good heat dissipation;
> Superior PC reflector-optic for low glare applications,and toughened glass protection;
> IP66 and IK10 for road lighting application;
> Professional 50(V)*120(H)°/75(V)*150°(H) optic for option;
> ±10°/-90°(<90W) or ±15°/-90°(>90W) lamp head adjustable;
Options:
> Driver and LEDs, to meet your requirements and lower the budget;
> Smart control and surge protector device available;
> Light pole adapter for different poles optional;
> Customized supported for special projects: Dialux simulation;

Why choosing Dualrays?

* More than 10 years experience in LED luminaries industry,built stable relationship with our customers ;

* Powerful production capacity and QC management system;

* Provide DIALux software for lighting design project for our customers;

* Built long term cooperation with customers in Europe, including projectors, traders and wholesalers, etc.;

* Our service and products are recognized from famous enterprises such as Jalasoft, Mercedes-Benz, Rewe, Nahkauf, Hagebau,etc.

* Always take customers' demand and product quality the first consideration.

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
* Roadways.
* Avenues.
* Walkways.
* Loading Area.
* Parking lot.
* Playground.
* Sport and Stadium.
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
30W/60W Version
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
90W,120W/150W/180W Version
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
Zigbee Wireless Intelligent Control Diagram
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
Zigbee Wireless Intelligent Control Operator Interface
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
DALI Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device

DALI Intelligent Control Diagram
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device 150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device

DALI Intelligent Control Operator Interface
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
Packaging Information
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
Shipment
150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
Q1: How many years warranty?
RE: 5 years warranty. We will take on the shipping cost and replacement if any quality problem occurred during this period.

Q2: What beam angles can you provide?
RE:Processional optics design,Type III Medium(70°x150°),Type I Short 50°x120° for option.
Q3: Can I have sample test?
RE: Yes, 1pcs ample order for testing is welcomed.

Q4: Production time?

RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.

Q5: Can you do DIAlux Simulation(light calculation)?

RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website or send after your inquiry.

Q6: How many shipping methods available?
RE: UPS, DHL, Fedex, TNT or Shipping by Air,by train(for Europe) or by sea for option.

Q7: Do you offer OEM or ODM?
RE: Yes. OEM and ODM service with customers‘ label is available,various choice for the package as below:
1. We can provide you with our present products with your own label;
2. We can modify our products as you request;
3. We can even develop totally new products based on your design;
Q8: What‘re the chips and drivers used?

RE: High brightness LUXEON LEDs light source,Meanwell drivers for standard configuration. Can change other brands according to customer's demand.

Q9: What Optics available?
RE: Type I, Type II, Type III, Type IV, Type V for option.
Q10: Dimming functions?
RE: 1-10V / PWM / Resistance / Timer/ DALI dimmable driver available.

Q11: Is there cheap shipping cost to import to our country?
RE: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much time.For urgent
orders,we suggest via air to airport plus our ship partner send to your door.
Q12: Labeling ?
RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).
Q13: Does the price include photocell controller?
RE: The photocell controller should be purchased separately.
Q14: What's the finishing color?
RE: Black RAL9017/White RAL9016
Please do not hesitate to contact us to get more information.
Let's meet DUALRAYS:

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device

Attending Hong Kong Lighting Fair:

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device

150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device


150W Outdoor Intelligent LED Street Light IP66 IK08 10KV 20KV Surge Protection Device
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
