1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
Specifications
Brand Name :
DUALRAYS
Model Number :
HB5 Series
Certification :
CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Place of Origin :
Shenzhen,China
MOQ :
2PCS
Price :
Negotiated
Payment Terms :
L/C, T/T, Western Union
Delivery Time :
5-15 Bussiness Day
Packaging Details :
Netural Package/OEM and ODM Package Available
Supply Ability :
50000PCS/Month
Input Voltage :
AC90V-305V
Material :
AL+PC
LEDs Light Source :
SMD3030
Surge Protection :
10KA 20KV/20KA 20KV
Warranty :
5 Years
IP Rating :
IP66
Description

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

Detailed Product Description

Item No.: HB5 Series Material: AL+PC
LEDs Light Source: SMD3030 IP Rating: IP66
CRI: >83Ra Beam Angle: 60°/90°/120°
Surge Protection: 10KA 20KV/20KA 20KV Warranty: 5 Years



1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

> 90% efficiency reduces light significantly;
> Constant voltage or constant current output, quick responds,no flicker, lightning protection, PFC function available;
> Good mechanical strength and heat dissipation;
> Variety of Beam Angle 60°/90°/120° optional;
> PIR SENSOR is Optional;
> IP65 and IK10 for all industrial areas of application;
> L80/B10 @ 50.000h;
> 5 years Guarantee;

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee


1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
* Sports Stadiums
* Landscape
* Factory
* Yard
* Square
* Supermarkets
* Exhibition center

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

Character/Power
100W
150W
200W
240W
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
A
Ø350mm
Ø350mm
Ø420mm
Ø420mm
B
210mm
210mm
220mm
220mm


1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
Packaging Information

Model No.
Net Weight/PCS
Outer Carton Size
G.W
Quantity/CTN
DR-HB100-CG2
5.7kg
L415xW390XH205mm
6.5kg
1PCS
DR-HB150-CG2
6.5kg
L415xW390XH205mm
7.6kg
1PCS
DR-HB200-CG2
7.2kg
L485xW460xH225mm
8.4kg
1PCS
DR-HB240-CG2
7.5kg
L485xW460xH225mm
8.6kg
1PCS


Shipment
1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

Q1: What is the warranty for the HB5 LED high bay?
RE: For the HB5 Series LED high bay,Dualrays provide 5 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

Q2: What is colour temperature?
RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
the warmer the light given by the LED:
Warm white = 3000±200K
Natural white = 4000±200K
Pure white = 5000±200K
Cool white = 5700±200K
Q3: Is there a MOQ?
RE: 2PCS.

Q4: What is the Lead time?
RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.
Q5: Can you do DIAlux Simulation?
RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

Q6: Do you offer mounting accessories?
RE: Yes, please contact us for details.
Q7: Do you offer OEM or ODM?
RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:
1. We can provide you with our present products with your own label;
2. We can modify our products as your request;
3. We can even develop totally new products based on your design;
Q8: What‘re the chips and drivers used?
RE: High brightness LUMILEDS LEDs light source,Meanwell/Sose drivers for standard configuration.

Q9: What is the CRI?
RE: Ra>80 for standard.
Q10: IP Rating?
RE: IP65.

Q11: Labeling ?
RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

Q12: Finish color?
RE: Standard colors: Black / White,other colors can be customized, based on MOQ 50PCS.

Q13: Dimming functions?
RE: DALI,PIR,1-10V diming available,built-in daylight sensor available for intellgent control for option.

Q14: Is there cheap shipping cost to import to our country?
RE: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much time.For urgent
orders,we suggest via air to airport plus our ship partner send to your door.

Q15:Can we get support if we have our own market position?
RE: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee

1-10V Diming Control UFO LED High Bay Light With PIR Sensor 5 Years Guarantee
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
