Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Specifications
Brand Name :
DUALRAYS
Model Number :
DR-HB150-CG2
Certification :
CE,RoHS,LM79,LM80,TUV/GS,SAA,RCM,CB and D-Mark Available
Place of Origin :
Shenzhen, China
MOQ :
2pcs
Payment Terms :
L/C, T/T, Western Union
Supply Ability :
50000PCS/Month
Delivery Time :
5-15 Bussiness Day
Packaging Details :
Netural Package/OEM and ODM Package Available
Material :
Aluminium Alloy
Rated Power :
100-240W
Rated Lumen :
16,000-38,400lm
CCT :
3000/4000/5700/6500K±200K
CRI :
>83Ra
Warranty :
5 years
LEDs Driver :
MOSO/SOSEN
Life Span :
50,000 Hours
Description

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays HB3 Series UFO LED High Bay Light-- Data Sheet

Model No DR-HB200-CGXP
Rated Power 150W
LEDs Typ/Qty 322
Luminous Flux 21,000±5%
Efficiency 160LPW
Color Temperature WW:3000±200K NW: 4000±200K DW:5000±200K CW: 5700±200K
Dimming Function 1-10VDC /DALI / PIR Sensor
Protections Short circuit/Over current/Over voltage/Over temperature
Color Index >80Ra
Beam Angle 60°/90°/120° for option
IP/Rating IP65
AC Input Vol AC100~240V 50/60Hz
Power Factor PF>0.95
Starting Time <0.1
Lumen Maintenance @ 6000 hrs >95%
Switching Cycle before Failure 100,000
Life Span 50,000hrs
Warranty 5 years
Dualrays HB3 Series UFO LED High Bay Light--Features:

1. Angle adjustable, beam angle of lens cover for optional: 60/90/120 degree.

2. Die casting Aluminum shell, good mechanical strength and heat dissipation, surface anti-corrosion coating processing, high anti-corrosion grade WF2,can be used indoor and outdoor prevent corrosion environment.
3. High quality DUALRAYS own-developed non-isolated power supply, AC100V~277V, 50/60Hz input voltage, constant voltage or constant current output, quick responds,no flicker,lightning protection, PFC function available.
4. Rod mounting, hook with chain mounting and heavy duty steel yoke mounting are available;
5. With high-strength tempered glass and die-casting Aluminum shell, high shock-proof level IK08;
6. DALI,PIR,1-10V diming available,built-in daylight sensor available for intellgent control;
7. CE,RoHS listed,5 years guarantee;

Dualrays HB3 Series UFO LED High Bay Light--Options:
> Driver: DUALRAYS Own-developed built-in driver,slim design,durable and compact.
> Controls and Dimming Zigbee wireless control / 1-10V Dimming / Daylight sensor.
> Reflector : PC reflector with / without cover.pipe mounting.
> Installation: loop hanging, ceiling mounting, wall mounting,
> Customized supported for special projects.

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
> Factories / Warehouses /Workshops
> Exhibitions & showrooms
> Barns and riding halls
> High rooms and halls
> Traditional lamp replacement


Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Character/Power
100W
150W
200W
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
A
Ø322mm
Ø322mm
Ø322mm
B
128mm
128mm
128mm


Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

DALI Device
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

DALI Intelligent Control Diagram
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

DALI Intelligent Control Operator Interface
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span

Dualrays 150W HB3 LED High Bay Light 160LPW High Efficiency 50000hrs Long Life Span
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!
