90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
Specifications
Brand Name :
DUALRAYS
Model Number :
DR-ST90-DG1
Certification :
CE, ROHS,TUV,SAA,LM79,LM80
Place of Origin :
Shenzhen,China
MOQ :
2PCS
Price :
Negotiated
Payment Terms :
Western Union, T/T, L/C
Supply Ability :
30000PCS/Month
Delivery Time :
5-15 business days
Packaging Details :
Netural Package,OEM/ODM Package Available,2PCS/CTN
Power :
90W
LEDs :
LUXEON SMD5050
System Efficiency :
150LPW
Color Temperature :
WW:3000K NW: 4000K DW:5000K CW: 5700±200K
IP Rating :
IP66
Switching Cycle before Failure :
100,000 Times
Life Span :
>50,000
Warranty :
5 years
Power Supply :
Meanwell/Sosen
Description

90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control

90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control

90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
> High brightness LUXEON SMD3030 LEDs,energy efficient - up to 150 lm/w;
> Die-casting Al for excellent heat dissipation;
> Superior PC reflector-optic for low glare applications,and toughened glass protection;
> IP66 and IK10 for road lighting application;
> Driver and housing separated by spacers;
> Professional 50(V)*120(H)°/75(V)*150°(H) optic for option;
> ±10°/-90°(<90W) or ±15°/-90°(>90W) lamp head adjustable;
> No UV or IR and completely mercury free;
> L80/B10 @ 50.000h;
> 5 years warranty,7 or 10 years warranty negotiated;

Options:
> Driver: ELG/HLG,Sosen;
> Controls and Dimming: 1-10V, DALI, PWM,Zigbee Wireless Dimming for option;
> 10KA SPD,20KA Meanwell SPD optional;
> 3-pins photocell controller ON/OFF,and 7-pins LORA/NEMA socket smart wireless control available;
> Zigbee module (Single-lamp Controller and centralized manager) with software for option;
> DALI driver and DALI Centralized Manager optional;
> Light pole adapter for different poles optional;
> Customized supported for special projects;
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
* Roadways.
* Avenues.
* Walkways.
* Loading Area.
* Parking lot.
* Playground.
* Sport and Stadium.

90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control

90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
Packaging Information
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control

Shipment
90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
Note: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much
time.For urgent orders,we suggest via air to airport plus our ship partner send to your door.

90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control

Q1: What is the warranty for the LED street light?
RE: For the LED street light,Dualrays provide 5 years warranty.If any quality problems on our side occured in this period ,we will take on the shipping cost and replacement.

Q2: What is colour temperature?
RE: Dualrays‘ LED lighting offer lamps in warm white, natural white,pure white and cool white with colour temperatures measured in Kelvin (K). The lower the colour temperature is,
the warmer the light given by the LED:
Warm white = 3000±200K
Natural white = 4000±200K
Pure white = 5000±200K
Cool white = 5700±200K
Q3: Is there a MOQ?
RE: No MOQ, Sample order for testing welcome.

Q4: What is the Lead time?
RE: Normally 3-5 business days for samples, 10-15 business days for bulk orders.
Q5: Can you do DIAlux Simulation?
RE: We have professional DIAlux team to support you, IES files also can be downloaded on our Website.

Q6: Do you offer mounting accessories?
RE: Yes, please contact us for details.
Q7: Do you offer OEM or ODM?
RE: OEM and ODM service with customers‘ label is available,various choice for the package as below:
1. We can provide you with our present products with your own label;
2. We can modify our products as your request;
3. We can even develop totally new products based on your design;
Q8: What‘re the chips and drivers used?
RE: High brightness NICHIA LEDs light source,Meanwell drivers for standard configuration.
Q9: What Optics available?
RE: LED Street Light: Type I, Type II, Type III, Type IV, Type V for option.

Q10: What is the CRI?
RE: Ra>70, Ra>80 optional.
Q11: IP Rating?
RE: IP66.

Q12: Labeling ?
RE: Neutral labeling/ Custom designed labels / Laser printing labels (at request).

Q13: Finish color?
RE: Standard colors: Black / White,other colors can be customized, based on MOQ 50PCS.

Q14: Dimming functions?
RE: 1-10V / PWM / Resistance / Timer/ DALI dimmable driver available.

Q15: Is there cheap shipping cost to import to our country?
RE: For small order,express will be best.And for bulk order,ship by sea or train(Europe destination) is the best,but take much time.For urgent
orders,we suggest via air to airport plus our ship partner send to your door.

Q16:Can we get support if we have our own market position?
RE: Please inform us your detailed mind on your market demand,we will discuss and propose helpful suggestion for you,to find the best solution for you.


90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control
Thank you for your using Dualrays LED luminaires, we regards quality first as our marketing philosophy from the design and package of all our
products,we here declare that all of our products are tested by professionals and obey strict quality standards,we have professional after-sale
service team to follow our customers,we promise that when you find any quality problems caused by the products quality itself within its
guarantee period,you can contact us freely. When confirmed by the QC Department, we will immediately help you to exchange or
maintain products for free.Shenzhen Dualrays Optoelectronics Co., LIMITED. will serve you with heart and soul!

90W Intelligent Outside LED Street Lamps150LPW Efficiency LORA or NEMA Socket Zigbee Wireless Control

Marketing Department
Tel: 0086-755-2306 6948
Fax: 0086-755-6164 1072
Zip Code: 518125
Web: www.DUALRAYS.com
Email: info@DUALRAYS.com
