D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving
D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving
D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving
D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving
D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving
D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving
D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving
D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving
Specifications
Brand Name :
DUALRAYS
Model Number :
DR-TP020-BHG2XPX
Certification :
CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available
Place of Origin :
Shenzhen,China
MOQ :
50pcs
Price :
negotiate
Payment Terms :
L/C, T/T, Western Union, paypal
Supply Ability :
50000PCS/Month
Delivery Time :
8-15 Business Day
Packaging Details :
Netural Package/OEM and ODM Package Available
Model No. :
DR-TP020-BHG2XPX
CCT/K :
5000K for Standard (3000K/4000K/5700K/6500K Optional)
IP Rating :
IP65
IK Level :
IK08
Material :
PC+AL
Lifespan/hrs :
52.000 Hrs (Ta=30℃@L70)
Description

D2.5 LED Triproof Lighting Hi-Slim & Buckle End-Cap Design For Labor Cost Saving

D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving

Features:

> Hi-slim design,elegent and fashional;
> Buckle Design End-cap,pretty Easy for Wiring and Installation;
> High Brightness SAN‘AN SMD2835 LEDs, DUALRAYS Own Developed High PF Flicker-free Driver;
> Full Plastic Material,Eco and Environment Friendly;
> IP65 / IK08 Protection;
> 120°beam angle;
> Linkabkle Through Double End Wiring;
> Multiple Installations: Suspension, Wall Mounting;
> No UV or IR and completely mercury free;
> L70/B20 @ 52.000h;
> Customized supported for special projects;
Options:
> Plug: European / Australia plug with 0.75mm2/1.5mm2/2.5mm2 3-pins or 5-pins (dimming) cable;
> Installation : Suspension, Wall Mounting;
Applications:
> Replacement for fluorescent NCF;
> Workshops and warehouse;
> Garage and car parks;
> Sport facility;
> Corridor/Gallery/Corridor;
> Outdoor & Indoor Locations;

Specification:

Model No. DR-TP020-BHG2XPX DR-TP030-BHG4XPX DR-TP040-BHG4XPX DR-TP040-BHG5XPX DR-TP050-BHG5XPX
System Watts/W 20W 30W 40W 40W
50W
System Efficiency/LPW 120LPW / 140LPW Optioanl
Lumen Output/lm 2.400/2.800±5% 3.600/4.200±5% 4.800/5.600±5% 4.800/5.600±5% 6.000/7.000±5%
Rated Input Voltage/V AC200~240V, 50/60Hz /(AC100~277V, 50/60Hz Optional)
LEDs Light Source SMD2835
SDCM <6
CCT/K 5000K for Standard (3000K/4000K/5700K/6500K Optional)
CRI/Ra >80Ra (>70Ra for Option)
Power Factor >0.94
THD <10%
Beam Angle(Optional) 120°
UGR <22
LED Driver DUALRAYS Own Developed High PF Driver
IP Rating IP65
IK Level IK08
Dimming(Optional) 1-10V
Sensor(Optional) No
Emergency(Optional) No
Protection Class ClassⅠ
Finishing Color(Optional) White RAL9016 Optional
Material PC+AL
Lifespan/hrs 52.000 Hrs (Ta=30℃@L70)
Operation Temp/℃ 40°C to + 50°C(-40°F to 122°F)
Storage Temp/℃ - 40°C to + 65°C(-40°F to 149°F)
Installation(Optional) Suspension / Ceiling Mounting Optional
Certificate CE(EMC+LVD),RoHS,ENEC ,D-Mark,SAA,RCM Available

Dimsion:

Character/Length
2ft
4ft
5ft
D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving
A
602mm
1202mm
1502mm
B
73.5mm
73.5mm
73.5mm
C
29mm
29mm
29mm

Optical & Photometric:

D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving

Installation:

D2.5 LED Triproof Lighting Hi-Slim & Buckle End Cap Design For Labor Cost Saving

RISK OF PERSONAL INJURY – READ and follow all WARNINGS and installation instructions.
Keep or give to the owner for future reference.

Risk of cuts: Wear gloves to prevent cuts or abrasions when removing from carton, handling, installing, and maintaining this product.
Risk of electric shock: This product must be installed in accordance with the applicable installation code by a person familiar with the construction and operation of the product and the hazards involved.
Risk of Fire: Minimum 194°F supply conductors. Consult a qualifed electrician to ensure correct branch circuit conductor. DUALRAYS® assumes no responsibility for claims arising out of improper or careless Installation or handling of this product.

Details Demo:

Shipment&Package:

Model No.
Net Weight/Kg
Outer Carton Size/mm
Gross Weight/Kg
QTY”/CTN
DR-TP020-BHG2XP
 14.9
700*305*210
15.8
12PCS/CTN
DR-TP030-BHG4XP
18.4
1300*305*210
19.8
12PCS/CTN
DR-TP040-BHG4XP
20.2
1300*305*210
21.6
12PCS/CTN
DR-TP040-BHG5XP
24.2
1600*305*210
25.8
12PCS/CTN
DR-TP050-BHG5XP
25.3
1600*305*210
26.8
12PCS/CTN
