Bright 10000lm Led Street Lighting Fixtures High Power LG Chip SMD 3535
Bright 10000lm Led Street Lighting Fixtures High Power LG Chip SMD 3535
Bright 10000lm Led Street Lighting Fixtures High Power LG Chip SMD 3535
Bright 10000lm Led Street Lighting Fixtures High Power LG Chip SMD 3535
Specifications
Brand Name :
Die Casting Man/OEM
Model Number :
ZHSL-09-100
Certification :
CE,ROHS, UL,SAA
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
By T/T 30% in advance and 70% after shipment EXW/FOB NINGBO, Western Union
Supply Ability :
10000PCS/Month.
Delivery Time :
7-30 days base on order quantity
Packaging Details :
Carton box with foam
Manufacturer :
Ninghai Zhouhua Die Casting Co.,Ltd
Material :
ADC12 Aluminum
Wattage :
100W
Fixture Color :
sandy dark grey
IP :
65
LED Color :
WW/NW/CW
CRI :
>70
Input Voltage :
AC85 - 265V
Frequency Range :
50 - 60Hz
Working Ambient Humidity :
10% - 90%
Working Ambient Temperature :
-30℃ - 50℃
Description

Bright 10000lm Led Street Lighting Fixtures High Power LG Chip SMD 3535

Description:

New Patent 100W SMD LED streetlight made of High quality Die Casting Aluminum housing +LG High lumen chip+Meanwell Driver

Quick Detail:

Name

100w led street lighting

Application

Use for Street

Color

Grey,black,White,or custom color

Feature

New Design

Lamp Luminous Flux(lm)

10000LM

Certificate

TUV/UL /CE/ROHS

Specifications

Model Number

ZHSL-09-100

Electrical Specifications

LED QTY

48PCS of LG chip

TotaLPower consumption

100W

Operation Voltage

85-265VAC or 12VDC or 24VDC

Operating Humidity

10%~90%

Working Temperature

-30 ~ 50°C

Power Fact(PF)

>0.95

Driver Efficiency

> 0.9

Photometric Specifications

LED Luminous Flux

12000 lm - Initial

10000 lm - Maintain

Led Luminous Efficiency

>100LM/W

CRI

Ra ≥ 70

LED Color

3000k-6500k

Mechanical Specifications

IP Rating

IP65

Warranty

3Years

Heat Radiator

die-casting body as heat sink

Lens

tempering glass

Fixture Dimension

622x292x112MM

Fixture Weight

6.5kgs(14.4lbs)

Packing Information

Packing Type

1unit /ctn

Packing Dimension

66 x33 x21 cm (20.5” x9.85” x8.3”)

Packing Weight

7.5kgs(16.6lbs)

1. The latest version of high power SMD LED Street Light Housing

2. State-of-art designing with completed die-casting body as heat sink offer the maximum heat management system,which can hold maximum 48pcs of 1-5W LG SMD led.

3. Patented anti-glare optic lense enable this street light give an maximum 120 degree light spread,with an asymmetrical polar curve.

4. IP65 protection grade.

5. User-friendly mechanical designing,easy to assemble the led,potic lense and led power supply.

6.The Led power supply is designed to installed with two U brackets,so any brand of led power supply can be easily installed.

Applications:

minor roads,Motorways,Major roads,roundabouts,crossing and industrial areas.Bright 10000lm Led Street Lighting Fixtures High Power LG Chip SMD 3535Bright 10000lm Led Street Lighting Fixtures High Power LG Chip SMD 3535Bright 10000lm Led Street Lighting Fixtures High Power LG Chip SMD 3535

Our service:

your inquiries will be replied in 24 hours in our working days.

  • 3years warranty under normal use.
  • Professional design provided.
  • Timely delivery guaranteed.
