Specifications
Brand Name :
Die Casting Man
Model Number :
SL-09-150
Certification :
CE
Place of Origin :
China
MOQ :
10pcs
Price :
Negotiation
Payment Terms :
By T/T 30% in advance and 70% after shipment EXW/FOB NINGBO, Western Union, L/C
Supply Ability :
10000PCS/Month.
Delivery Time :
7-30 days base on order quantity
Packaging Details :
Carton box
Material :
diecasting Aluminum
CRI :
>70
Fixture Color :
Gray
Input Voltage :
AC85 - 265V
Working Ambient Temperature :
-30℃ - 50℃
IP :
66
Lamp Power :
150W
Color Temerature :
3000 - 6500K
Description

Waterproof External Outdoor Led Street Lights For Roadway Urban Lighting Systerms

Item No.: SL-09-150

Code ZHSL-09-30 ZHSL-09-50 ZHSL-09-100 ZHSL-09-150
Power 40W 60W 100W 150W
Color Temperature 3000-6500K 3000-6500K 3000-6500K 3000-6500K
Efficiency ＞120LM/W ＞120LM/W ＞120LM/W ＞120LM/W
Voltage AC100-240V AC100-240V AC100-240V AC100-240V
Power Factor PF≥0.95 PF≥0.95 PF≥0.95 PF≥0.95
CRI(Ra) Ra≥70 Ra≥70 Ra≥70 Ra≥70
Ambient Temperature -40-50℃ -40-50℃ -40-50℃ -40-50℃
Ambient Humidity 20%-90%RH 20%-90%RH 20%-90%RH 20%-90%RH
Lifetime(hrs) 50000 50000 50000 50000
IP Rate IP66 IP66 IP66 IP66
Installation Pipe Diameter Φ50/60mm Φ50/60mm Φ50/60mm Φ60/70mm
Installation Height 4-7m 6-8m 8-10m 10-12m
Net Weight 3.4kg 6.0kg 3.4kg 9.0kg
Gross Weight 4.6kg 7.0kg 4.0kg 10.5kg
Packing Size(mm) 490*250*210/2pcs 520*250*210/2pcs 675*315*155/1pcs 895*395*175/11pcs


LED Engine Module

· LED life time of 30,000+ hours

· High power integrated packaging LED chips, 120° beam spread available

· Minimum CRI of 70, custom CRI available

· Operating temp: -30º C to +60º C

· No toxic chemicals / ROHS compliant

· Low Tj for long life, low lumen depreciation

· CE certified, meets ROHS standards

· Eligible for Rebates, Design Lights Consortium® Qualified*

· 50-80% energy savings

· Manufactured in the China

· Standard distribution is Type V, others distributions available
Electrical

· Standard AC input of 85-265v VAC, up to 480v available

· EMI filter: 47CFR, part 2, part 15

· Power factor: >0.9

· Total harmonic distortion: <20%

· Surge protection: IEC/EN 61000-4-5 EMC test standard

· Licensed electrician required for installation
Housing

· Rugged, fully sealed, die-cast aluminum housing

· UV-resistant, multi-layer, architectural color, powder coat finish

· High impact, heat resistant, tempered lens
Energy Control Options

· Motion detection available

· Photo sensors available

Application:
Motorways , Major roads, minor roads, roundabouts, crossings and industrial areas.

Available housing colors: Black, Grey, White.
