100W Outdoor Led Street Lights Nema Zhaga available 1-10V Dimming driver
100W Outdoor Led Street Lights Nema Zhaga available 1-10V Dimming driver
100W Outdoor Led Street Lights Nema Zhaga available 1-10V Dimming driver
100W Outdoor Led Street Lights Nema Zhaga available 1-10V Dimming driver
Specifications
Brand Name :
no brand
Model Number :
YASL-105-100
Certification :
CE, RoHs, ENEC, CB
Place of Origin :
NINGBO,CHINA
MOQ :
1-2 pcs
Price :
Negotiation
Payment Terms :
By T/T 30% in advance and 70% after shipment EXW/FOB NINGBO, L/C, T/T, Western Union
Supply Ability :
10000PCS/Month.
Delivery Time :
7-30 days base on order quantity
Packaging Details :
Carton box with foam
Power :
50W
Efficiency :
130lm/w
Lumen :
6500lm
LED :
Lumileds
Housing Color :
Gray
Pole size :
50mm/60mm
Description

50w Economic Cheap Price Outdoor LED Street Lights For Major Road

50W elegant outdoor led street light

Product Specification

Product Datasheet
Item No. SL105-30W-S SL105-50W-S SL105-60W-S SL105-80W-M SL105-100W-M SL105-120W-L SL105-150W-L
Power 30W 50W 60W 80W 100W 120W 150W
Lumen Efficiency 130lm/w 130lm/w 130lm/w 130lm/w 130lm/w 130lm/w 130lm/w
Lumen 3900lm 6500lm 7800lm 10400lm 13000lm 15600lm 19500lm
Product Size (mm) 456x122x13 456x122*13 456x122*13 536x166x13 536x166*13 618x461x13 618x461*13
Electrical Data
Working Voltage AC100-265V 丨 50/60Hz
LED: Lumileds / Epistar / SANAN
CCT 3000K, 4000K, 5000K ,6000K
CRI Ra>70 (standard)/ Ra>80
Driver local
THD <15%
Power Factor(PF) PF>0.9
IP Rating IP66
IK Rating 1K09
Holder 50mm/B60mm (standard)
Body Material Hign pressure die-cast aluminum
Housing Calor Dark Grey/Black/Light Grey (availabel on request)
Cover Material UV-resistant Polycarbonate
Working Environment -20℃ ~+50℃ , 10%~90%RH
Lifespan L70 at 25℃ > 50,000hrs
Mounting Type Side entry or Vertical pole mounted ±15°
Dimmable 1-10V Dimming /Timer Dimming
Protecdion Class Class I (standard) / Class Ⅱ
Standards CE, RoHS, ENEC, CB, LM79. LM80, TM-21, IP66, IK09
Available on request NEMA socket (3/5/7pins), ZHAGA socket. Short cap, Photocell., Motion sensor, NTC. OLC, DALI Dimming
Reasonable tolerance Watt: ±10%,CCT:±500K, Lumen efficiency: ±5%

100W Outdoor Led Street Lights Nema Zhaga available 1-10V Dimming driver

Equipment

100W Outdoor Led Street Lights Nema Zhaga available 1-10V Dimming driver

Exihibition

100W Outdoor Led Street Lights Nema Zhaga available 1-10V Dimming driver

Ningbo Die-casting Man Techonology Co.,LTD. was founded in 1996 and is located in Ninghai Mould Centre,

close to Ningbo port and Shanghai port.

Factory covers an area of 15,000 square meters and has 100 employees. We are a professional factory engaged in research,

design, production, sale and service of street light and die-casting injection OEM and ODM products.

Our products sale mainly to Europe, Asia and domestic /dəˈmestɪk/ market.

We have die-casting injection, CNC machining, metal punching, powder painting, assembling and testing in house.

Our R&D department will develop 5-10 new products yearly. Besides design and production process,

we work under ISO9001 quality control system to make sure our quality is consistent and well controlled.

Our main products are street light and die-casting OEM injection products.

Current we have 24 series street light and various customer OEM products.

Our street lights are available from 20W to 240W mainly. Every series we have small, medium and large size and some have mini version.

If you do not like current version, we can also design the one to meet your market. We are a company never stand still on products and service.
