Specifications
Brand Name :
Die-casting Man
Model Number :
YASL-24-100
Certification :
CE ROHS ENEC
Place of Origin :
CHINA
MOQ :
1 PCS
Price :
USD28/PCS
Supply Ability :
30pcs/per day
Delivery Time :
25 days
Packaging Details :
PE bag+bubble+carton
Material :
ADC 12 Aluminum
Input Wattaage :
80~120w
Color Temperature :
3000/4000/6500K
Color Rendering Index :
Ra≥70
LED Lifetime :
50000h
Protection Grade :
IP66 IK08
Temperature of working condition :
-40~50℃
Description

80W 90W 100W 120W
Road Outdoor LED street light housing IP66 Aluminum die-casting housing

Material:ADC12 AluminumWattage:80~120W
IP:66CRI:≥70
Color Temperature:3000/40000/6500KInput Voltage:AC90 - 265V
Frequency Range:50 - 60HzWorking Ambient Temperature:-40℃ - 50℃
Working Ambient Humidity:20% - 90%RHLED Lifetime:50000h

Part Number:YASL-25
Production Lead Time:7-30 Days
MOQ:1 PCS
Shipping:EXW / FOB NINGBO
Finish Color:Double gray;Sandy black;

Prodcut Specification

Prodcut CodeYASL-25-100YASL-25-150YASL-25-240
Input Wattage30W/40W/50W60W70W80W100W120W/150W
Color Temperature3000/4000/6500K3000/4000/6500K3000/4000/6500K
Luminous Flux5750~6250lm11500~12500lm16500~18750lm
Input VoltageAC90~305VAC90~305VAC90~305V
Frequency Range50/60Hz50/60Hz50/60Hz
Power FactorPF≥0.95PF≥0.95PF≥0.95
Color Rendering IndexRa≥70Ra≥70Ra≥70
Working Temperature-40~50℃-40~50℃-40~50℃
Humidity of Working Condition20%~90%RH20%~90%RH20%~90%RH
LED Lifetime50000H50000H50000H
Protection GradeIP66IP66IP66
Installation Pipe Diameterφ60mmφ60mmφ70mm
Installation Height4~8m6~10m8~12m
Net Weight3.8kgs5.7kgs7.20kgs
Gross Weight4.0kgs6.0kgs7.50kgs
Product Size680x270x160mm820x320x160mm920x370x180mm

YASL-25-100

Ac Motion Sensor 6500k Outdoor Led Street Lights 120w

Ac Motion Sensor 6500k Outdoor Led Street Lights 120w

Ac Motion Sensor 6500k Outdoor Led Street Lights 120w

Ac Motion Sensor 6500k Outdoor Led Street Lights 120w

Ac Motion Sensor 6500k Outdoor Led Street Lights 120w
Is there anything else you want to know about this lamp?
6. Q:Do you sell only whole lamps?Or I can just buy the empty housing?
A:It’s up to you,we can also sell empty housing,even you just by the die-casting housing without powder coating is also no problem.

  • Q:What brand of driver do you use?

A:The brand we usually use is Inventronics,Sosen these China local brand,and PHILIPS,MEANWELL these international brand,Customers can also specify brands,it’s no problem.

  • Q:About the powder coating,i have a question,What colors do you usually use?Can we customize the color?

A:The colors we usually use are black and gray,you can also customize other color,just tell us the RAL number,we will according the RAL number to do the powder coating.

  • Q:Ok,that’s good,So if I want to specify a color,will you charge extra cost?

A:will not,but we will require MOQ500 pcs.

  • Q:ok,last question,Do you accept OEM?

A:Of course we can,we have own die-casting machine and mould design team,must be able to meet your requirements,and we already have a lot of OEM customers.

Electrical

· Standard AC input of 90-305V,up to 480v available

· EMI filter: 47CFR, part 2, part 15

· Power factor: >0.9

· Total harmonic distortion: <20%

· Surge protection: IEC/EN 61000-4-5 EMC test standard

· Licensed electrician required for installation

Housing

· Rugged, fully sealed, die-cast aluminum housing

· UV-resistant, multi-layer, architectural color, powder coat finish

· High impact, heat resistant, tempered lens

Energy Control Options

· Motion detection available

· Photo sensors available
