IP66 30w 40w 50w 60w 70w 80w 100w LED Garden Light
IP66 30w 40w 50w 60w 70w 80w 100w LED Garden Light
Specifications
Brand Name :
Die-casting Man
Model Number :
YAUB-09-90B
Certification :
CE, RoHs, ENEC, CB
Place of Origin :
CHINA
MOQ :
1pc
Price :
Negotiable
Payment Terms :
T/T, 30% T/T as deposit, 70% T/T balance before delivery(EXW) or against shipping documents(FOB Ningbo), L/C
Supply Ability :
30000pcs/month
Delivery Time :
7-10 days based on order QTY
Packaging Details :
1pc/bag/foam/carton, pallet optional
Material :
Die Casting Aluminium
Power :
30-100W
Input Voltage :
220-240Vac
Optical Effect :
130~170 lm/w(Optional)
Protectin Grade :
IP66
Protection level :
IK08
Power Factor :
PF≥0.95
Color rendering index :
Ra≥70
Frequency Range :
50/60Hz
Working conditions range :
-40～45℃ 20%～90%RH
Size :
465x465x197 mm
Description

Products Description

Product Datasheet
Item No. YAUB-09B-90
Power 90W
Lumen Efficiency 130lm/w
Lumen 11700lm
Product Size (mm) 465X465X197
Electrical Data
Working Voltage AC100-265V 丨 50/60Hz
LED: Lumileds / Epistar / SANAN
CCT 3000K, 4000K, 5000K ,6000K
CRI Ra>70 (standard)/ Ra>80
Driver local
THD <15%
Power Factor(PF) PF>0.9
IP Rating IP66
IK Rating 1K09
Holder 50mm/B60mm (standard)
Body Material Hign pressure die-cast aluminum
Housing Calor Dark Grey/Black/Light Grey (availabel on request)
Cover Material UV-resistant Polycarbonate
Working Environment -20℃ ~+50℃ , 10%~90%RH
Lifespan L70 at 25℃ > 50,000hrs
Mounting Type Side entry or Vertical pole mounted ±15°
Dimmable 1-10V Dimming /Timer Dimming
Protecdion Class Class I (standard) / Class Ⅱ
Standards CE, RoHS, ENEC, CB, LM79. LM80, TM-21, IP66, IK09
Available on request NEMA socket (3/5/7pins), ZHAGA socket. Short cap, Photocell., Motion sensor, NTC. OLC, DALI Dimming
Reasonable tolerance

Watt: ±10%,CCT:±500K, Lumen efficiency: ±5%

IP66 30w 40w 50w 60w 70w 80w 100w LED Garden Light

IP66 30w 40w 50w 60w 70w 80w 100w LED Garden Light

IP66 30w 40w 50w 60w 70w 80w 100w LED Garden Light
