72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication
72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication
72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication
72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication
Specifications
Brand Name :
LEDCORP
Model Number :
LC72-N5050-RGB
Certification :
UL/CE/RoHS
Place of Origin :
China
MOQ :
100meters/20reels
Price :
negotiation
Payment Terms :
T/T , PayPal
Supply Ability :
500,000mters per month
Delivery Time :
15 working days
Packaging Details :
Anti-Static Pack, 12KG/Carton
Led :
5050
Qty/m :
72 LEDs/m
Voltage :
12/24V
Power :
15.6 w/m
Color :
RGB
Controller :
RGB Controller
Packing :
5 m/roll
Angle :
120°
PCB :
10mm
IP :
IP20-68
Lifespan :
>35000 hrs
Warranty :
3 yrs
Weight :
0.2 kg/roll
Description

72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication

72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication

72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication

RGB 5050 72LED is 5m long flexible strip with5050SMD 360LED as source, 10/12mm white PCB (2Oz) in 12V, 10mm white PCB (2Oz) in 24V, from IP20 to IP68 rated with 3M or clips mounted easily.

Application area:

1. Architectural decorative lighting
2. Archway, canopy & bridge edge lighting
3. Amusement park, theater & aircraft cabin mood lighting
4. Emergency hallway lighting
5. Auditorium walkway lighting.
6. Stairway accent lighting
7. Concealed lighting
8. Backlighting for signage letters
9. Cove lighting

Product advantages:

1. More Lumens per watt

2. Less Lumens depreciation, <0.3% in 1000h, <3% in 10000h

3. No faulty of LEDs, 0% in 10000h

4. Uniform light, even light output

5. Consistent light color of LEDs

6. Consistant brightness from the front to the end


Technical details:

Details

Item

Unit

Specification

Physical data

LED type

SMD

5050SMD

LED Qty /meter

LED/m

72

Dimensions

mm

10*2*5000 (W*H*L)

Type of protection

IP

IP20 / IP65

Working temperature

°C

0-40°C

Electrical data

Power

w/m

15.6

Voltage

VDC

12 (24 option)

Optical data

Beam angle

degrees

120

Light color

　

RGB

Color BINs

　

Wave Length

nm

Red : 619 - 635 nm

Green : 510 - 530 nm

Blue : 460 - 480 nm

Color rendering index

CRI

70-90

Order reference

HS code

94054090

Part. no

LC72-N5050-RGB-IP20-12/24

LC72-W5050-RGB-IP65-12/24

LC72-W5050-RGB-IP68-12/24

Dimension:

72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication

72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication

72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication

Installation:

72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication

Packing details:

Part No.

HS code

Packaging unit

meters per box

reels per box

Dimensions(mm) LxWxH

Gross weight

Volume(cbm)

LC60-N5050-RGB-IP20

94054090

One Pack

5m

1reel

150*150*12

0.11kg

0.00027

Shipping box

250m

50reel

500*350*250

12kg

0.04375

LC60-W5050-RGB-IP65

94054090

One Pack

5m

1reel

220*220*13

0.22kg

0.00063

Shipping box

100m

20reel

500*350*250

12kg

0.04375

72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication

72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication

72 LEDs / m Waterproof RGB LED Tape Lights IP65 Low Lumens Depreication
