Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20
Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20
Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20
Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20
Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20
Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20
Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20
Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20
Specifications
Brand Name :
J-STAR
Model Number :
JSPL-24100
Certification :
CE ROHS SAA CB
Place of Origin :
CHINA
MOQ :
10
Price :
USD 3.3 PCS
Payment Terms :
Western Union, T/T
Supply Ability :
1000000
Delivery Time :
10-15DAYS
Packaging Details :
white inner box and carton
Material :
Aluminum
IP Rate :
IP20
Color :
Silver
Usage :
LED Signs, LED Strips, MR14 Spot light, LED Modules
MOQ :
10pcs
Efficiency :
86%
Description

Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20

Model JSPL-24100 LED Screen Power Supply
Rated load Power 100W
Ouput voltage 24V
Ouput Current 4.15A
Input Voltage 200-230V
Dimension 200*53*23.4mm
Cooling Mode Nature cooling,self-cooling
Efficiency 87%
Frequency 47-63%
Adjustable range for DC voltage 11.5~12.51V
Weight(KG) 0.21
pcs/ctn 100
Output Voltage range ±10%
Overload protection 115%-150% hiccup mode, auto-recovery
Over-voltage protection 115%-150% hiccup mode, auto-recovery
Temperature coefficient ±0.03%/℃(0~50℃)
Setup, rise, hold up time 200ms, 100ms, 20ms
Withstand voltage I/P-O/P:1.5KVAC I/P-FG:1.5KVAC O/P-FG:0.5KVAC
Isolation resistance I/P-O/P, I/P-FG, O/P-FG:100M Ohms/500VDC
Working temperature and humidity -10℃~+60℃(Refer to output load derating curve),
Store temperature and humidity -10℃~+85℃,Indoor or dry condition
Certification BIS CE ROHS
Warranty 2 years

Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20

Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20

♦♦ Our Service

1. Your inquiry related to our products or prices will be replied in 24hrs;
2. Well-trained and experienced staffs to answer all your enquires in fluent English;
3. OEM&ODM, any your customized lightings we can help you to design and put into product;
4. Distributoership are offered for your unique design and some our current models;
5. Protection of your sales area, ideas of design and all your private informaton
6. Provide lifelong warranty for long-term cooperation.
7. After you buy this product, we will provide you with attentive after-sales service. Our engineers will carefully guide the installation and usage for you. That will includes connection of the controller and the light, and also the control software.

FAQ

1. Q: When can I get the price?

A: We usually quote within 24 hours after got your inquiry. If you are urgent to get the prices,

please call us or tell us in your email so that we will give priority to your inquiry .

2, Q: Do you accept the OEM&ODM?

A: Yes,OEM or ODM service are available.

3, Q: May I get samples to test quality and how long can I get them?

A: Yes, quote of sample is same as normal order and can be ready in 3-5 days.

4, Q: What is the MOQ?

A: One piece is OK. Because any order is from sample.

5, Q: Can you accept small trial order?

A: Yes, no matter large or small trial order, your needs will get our full attention. It’s our great honor to cooperate with you.

Silver Color Low Voltage LED Screen Power Supply 24V 100W IP20
