Slim Size Outdoor Waterproof LED Power Supply 24v 2.5A Aluminum Housing
Slim Size Outdoor Waterproof LED Power Supply 24v 2.5A Aluminum Housing
Slim Size Outdoor Waterproof LED Power Supply 24v 2.5A Aluminum Housing
Slim Size Outdoor Waterproof LED Power Supply 24v 2.5A Aluminum Housing
Slim Size Outdoor Waterproof LED Power Supply 24v 2.5A Aluminum Housing
Slim Size Outdoor Waterproof LED Power Supply 24v 2.5A Aluminum Housing
Specifications
Brand Name :
J-STAR
Model Number :
JSSF-24060
Certification :
CE ROHS SAA CB
Place of Origin :
CHINA
MOQ :
100
Price :
welcome
Payment Terms :
T/T, Western Union, Western Union, MoneyGram, T/T
Supply Ability :
1000000
Delivery Time :
10-15DAYS
Packaging Details :
white inner box and carton
Output Frequency :
43-60Hz
Mode :
60W Waterproof LED Power supply
Material :
Aluminum housing
Usage :
24V LED Flood lights, 24V LED Modules
Wattage :
60watt full power loading
warranty :
3 years
Description
Slim Size Outdoor Waterproof LED Power Supply 24v 2.5A Aluminum Housing
Quantity(Pieces) 1 - 200 201 - 500 501 - 2000 >2000
Est. Time(days) 3 5 7 To be negotiated

24v 2.5a 60w constant voltage waterproof IP67 LED driver LED power supply for LED strips
Features:
1. AC input range selectable by switch
2. Protections: Short circuit / Overload / Over voltage / Over temperature
3. 100% full load burn-in test
4. Low cost, high reliability
5. 36 months warranty
Specification
Model
JSSF-12060
JSSF-24060
JSSF-05060
Dc output voltage
12V
24V
5V
Rated output current
5.0A
2.5A
12A
Output current rage
0~5A
0~2.5A
0~12A
Rated Power
60W
60W
60W
Wave and noise
120mVp-p
150mVp-p
150mVp-p
Inlet stability
±0.5%
±0.5%
±0.5%
Load stablity
±1%
±0.5%
±0.5%
Efficiency
78%
80%
82%
Adjustable range for DC voltage
±10%
±10%
±10%
AC input voltage range
AC100~240V 47~63Hz;240~370VDC
Input current
0.1A/230V
AC INnrush current
Cold-start current 30A/230VAC
Overload proctection
105%~150% Tpye:Foldback current limiting Reset: auto recovery
Setup rise hold up time
200s,100ms,20ms
Withstand voltage
Input and output internal 1.5KVAC,Input and enclosure 1.5KVAC,Output and enclosure 0.5KVAC
Isolation resistance
Input and output internal Input and enclosure,Output and enclosure 500VDC/100MΩ
Working temperature
-10°C~+60°C
Overall dimension
222*30*20mm
Safety standards
Meet EN60950 requirement
EMC standards
Meet EN55022 class A requirement
Weight
0.55Kgs
Application Field
Packing & Delivery
About Us

Slim Size Outdoor Waterproof LED Power Supply 24v 2.5A Aluminum HousingSlim Size Outdoor Waterproof LED Power Supply 24v 2.5A Aluminum Housing

Found in 2013, Zhuhai J-STAR Lighting Manufacturing limited which located in China Lighting capital-Zhongshan City Guangdong province.Now J-star Lighting have set up production department,R&D department, sales department, after-sales department as a whole system complying with” customers firstly. Golden quality” cooperating idea,keeping on customers requirement oriented, working on technology as core of development basic on science and humanized management to create a completed modern enterprise J-star lighting has a group of professional production and research team for LED Power supply manufacturing supporting all series of testing and production.

We achieved independent automatic producing LED Power supply And we are keeping developing new products and ODM it is avalaible for our factory Our company production ranges: LED Power supply all series LED waterproof power supply(DC12V/24V/36V/48V) LED Rain-proof Power supply(DC5V/12V/24V) LED Switching Power supply( DC12V/24V) LED Indoor slim size power supply(DC12V/24V) LED Dimmable Power supply(DC12V/24V)

We are keeping on innovating for new products to combine the marketing development. OEM and ODM it is available for clients requirement. Welcome your joining with us and growing up together.

Choice us, let us work together and create a brilliant future
