Metal Case 12V constant Voltage Constant Current Power Supply 8.3A 120W
Metal Case 12V constant Voltage Constant Current Power Supply 8.3A 120W
Metal Case 12V constant Voltage Constant Current Power Supply 8.3A 120W
Metal Case 12V constant Voltage Constant Current Power Supply 8.3A 120W
Metal Case 12V constant Voltage Constant Current Power Supply 8.3A 120W
Metal Case 12V constant Voltage Constant Current Power Supply 8.3A 120W
Metal Case 12V constant Voltage Constant Current Power Supply 8.3A 120W
Metal Case 12V constant Voltage Constant Current Power Supply 8.3A 120W
Specifications
Model Number :
JSPL-100-12
Brand Name :
J-STAR
Certification :
CE ROHS SAA CB
Place of Origin :
CHINA
Cooling way :
Nature self-cooling
Material :
Aluminum case
Type :
Constant Voltage 12V
Rated Power :
100W Max
Description

Metal Case 12V Constant Voltage Constant Current Power Supply 8.3A 120W

AC/DC 12V LED switch power supply 12V 8.3A power supply metal case 120W Transformer SMPS for cctv camera and led light

Product Description

12V 8.3A Technical Specification
Model No. JSPL-100-12
Input Voltage AC 100-240V Worldwide
Vibration Input Voltage Range AC 95-265V
Frequency 50-60Hz
Output Voltage DC 12V
Current 8.3A
Power 100W
Typical Efficiency 73%
Adjustable Range of Voltage DC 12V-12.5V
Max. Ripple & Noise 250mV
Protection Over Load 105-115% of Rated Output Power
Short Circuit Protection Type: Auto Recovery
Electric Strength High-pot test 3KV AC
Environment Working temperature and humidity -10°C~+60°C,20~90%RH
Store temperature and humidity 20°C~+85°C,10~95%RH
MTBF >200K hrs.@25°C(MIL-HDBK-217F)
Warranty 2 year
Feature Dimension(L*W*H) 159*98*42mm
Weight 345g
Inner box size 165*103*46mm
Inner box weight 29G
PCS/CTN 50 PCS/CTN
CTN size 53*26*43cm
GW/CTN 20kg
Safety & EMC Safety Standards EN55015/EN61000-3-2/EN61000-3-3

Application

Metal Case 12V constant Voltage Constant Current Power Supply 8.3A 120W

Packaging & Shipping

Safe packing, brown box or color box packing can be customize

Metal Case 12V constant Voltage Constant Current Power Supply 8.3A 120W
