P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory
P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory
P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory
P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory
P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory
P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory
Specifications
Brand Name :
Smart LED
Model Number :
P7.62
Certification :
CE,ROSH,FCC,EMC
Place of Origin :
China
MOQ :
no requirement
Payment Terms :
T/T
Supply Ability :
no requirement
Delivery Time :
2-3 Days
Packaging Details :
Paper box package
Item :
P7.62 LED module
LED Lamp :
SMD 3528
Dot Density :
17222
Resolution :
64*32
Protective Grade :
IP33
Refresh Rate :
1920Hz
Brightness :
500mcd
Driving Method :
1/16 Scan
Module weight :
800g
Guarantee :
2Years
Description

P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory
P7.62 488*244mm SMD RGB LED Module -Easy install Play video ,Text,Photo 2Years Guarantee

Applications
P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory

Product Features
* Cabinet Install to the wall,Module magnet service
* Used LED Processor can open 2 windows on the LED Display.
* Power supply and Controller service from the front side.

What we can do

* Project advise,Make the easy project design,easy for install and service

* Free on-line support

* We will send the setting file send with the goods. And also we will keep the Project file.



P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen FactoryP7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory

P7.62 SMD indoor
Description:
Size: 488mm*244mm
Resolution: 64dots*32dots
Lamp: SMD 3528
Driving Method: 1/16 Scan
Module brightness:500mcd
Display Fresh requency: 1920Hz
Working environment: Indoor
Parameter:

Pixel pitch7.62 mm
LED Lamp type3in1RGB 3528
Module size244mmx244mm
Pixels Density17222 pixel/㎡
Brightness500cd/㎡
Scan type1/16 Scan
Frame Rata60HZ
Maximum consumption 700W/㎡
Ave power consumption250W/㎡
Led module weight9.18kg/㎡
Led display weight(Die-case)28kg/㎡
Working Temp-20℃ to +60℃
Horizontal View Angel140degree
IP gradeIP33
Cabinet suggest512mm*512mm



Production line
P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory



P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory




Packaging and shipping
Packing:1.Paper box packing and Water proof packing
Delivery:Shipping by sea,air or DHL,multiple shipping ways for your choice.

P7.62 Indoor Multi Screen LED Video Display Panel High Definition Clear LED Video Board Shenzhen Factory
