Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption
Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption
Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption
Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption
Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption
Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption
Specifications
Brand Name :
SMART LED
Model Number :
P10 960*960 Sign board
Certification :
CE,ROSH,FCC,EMC
Place of Origin :
China
MOQ :
no requirement
Payment Terms :
T/T, Western Union
Supply Ability :
no requirement
Delivery Time :
15Days
Packaging Details :
Wooden package
Item :
P10 SMD Outdoor Full color
LED Lamp :
SMD 3535
Dot Density :
10000
Dricing Method :
1/2 Scan
Cabinet Size :
960mmx960mm
Cabinet Resolution :
96*96
Protective Grade :
IP65
Refresh Rate :
>1920Hz
Brightness :
6500mcd
Cabint Materials :
Iron
Description

Outdoor LED Sign board Watter proof P10 10.56m*4.8m Energy onservation system

Applications

Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption

Product Features

* Cabinet Install to the wall,Module magnet service

* Used LED Processor can open 2 windows on the LED Display.

* Power supply and Controller service from the front side.

What we can do

* Project advise,Make the easy project design,easy for install and service

* Free on-line support

* We will send the setting file send with the goods. And also we will keep the Project file.

Energy Saving LED Digital Signage Display 300W / Cabinet Low Power ConsumptionPH4mm LED SMD Outdoor Display Specification
Technicial Parameters
LED Parameters
No. Item Luminous Intensity Viewing Angle(H/V) Wavelength Test Condition
1 Red LED (Epistar DICE) 800-1000 140º/120º 620-630nm 25℃,20mA
2 Green LED(Epistar DICE) 1300~1500 140º/120º 520-535nm 25℃,20mA
3 Blue LED (Epistar DICE) 250~500 140º/120º 465-475nm 25℃,20mA
Module Specifications
1 Pixel Pitch 10mm Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption
2 Pixel Configuration 3-in-1, SMD 3535
3 Module Resolution 32dots X 16dots
4 Module Pixles 512dots
5 Module Size 320mm X 160mm
6 Module power 5V7.2A 36W
Cabinet Specification
1 Cabinet Size(WXHXD) 960mmLx960mmHx100mmD Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption
2 Cabinet Resolution 96x96 pixels
3 Module Quanity 18 pcs
4 Cabinet Pixels 9216 dots
5 Pixel Density 10000 dots/m2
6 Average Power Consumption 300W/cabinet
7 Max. Power Consumption 1000W/cabinet
8 Material Alum+Magnet
9 Cabinet Weight 35KG
10 Protective Grade IP65
Screen Parameters
1 Whole screen size 10.56mx4.8m = 50.68sqm

Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption


Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption
2 LED Display piexl 1056 * 480
3 Cabinet quantity 55pcs
4 Brightness ≥6500 mcd/㎡
5 Brightness(Max./Min.) 1.2:1
6 Driving Method 1/2 Scan
7 View Angle Horizontal 140° Vertical 120°
8 Optimal Viewing Distance 6M
9 Brightness Control Red,Green and Blue 256 Grade/Each
10 Refresh rate >1920HZ
11 Frame Frequency 60Hz
12 Input Voltage AC220V/50Hz or AC110V/60Hz
13 Defects Rate ≤0.00001
14 Power Consumption Max.: 800W/㎡
Average: 300W/㎡
15 Screen weight ≤35kg/㎡
16 MTBF >10,000 hours
17 Life span ≥100,000 hours
18 Module Display Brightness Uniformity <2%
19 Earth Leakage Current <3mA
20 Protective Grade IP65
21 Temperature-operating ﹣25℃～45℃
22 Humidity-operating 10%～95%
23 Controlling system HD-Player Wifi
24 Operating System WIN7/WIN8/WIN10
Remarks:
1. Software and User’s manual in English included.
2. 30% Down Payment before Production, Balance before shippment
3. Lead time:15 working Days against down Payment
4. Two Years Maintain Replacement free.

Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption

Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption

Energy Saving LED Digital Signage Display 300W / Cabinet Low Power Consumption
