1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory
1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory
1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory
1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory
1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory
1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory
Specifications
Brand Name :
SMART LED
Model Number :
P4 Indoor LED Display
Certification :
CE,ROSH,FCC
Place of Origin :
China
MOQ :
no requirement
Payment Terms :
T/T
Supply Ability :
no requirement
Delivery Time :
12 Days
Packaging Details :
Wooden package,
Item :
P4 SMD Indoor Full color
LED Lamp :
SMD 2020
Dot Density :
111111 led
Driving method: :
1/32 Scan
module Size :
192*192mm
module Resolution :
64*64
Protective Grade :
IP33
Refresh rate :
>1920Hz
Brightness :
1000mcd
Cabinet Materials :
Aluminum
Description

1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory

P4 Indoor HD-LED Video screen Magnet Install 1920Hz Screen Resolution:1152 * 768

Applications

1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory

Product Features

*Cabinet Install to the wall,Module magnet service

*Used LED Processor can open 2 windows on the LED Display.

*Power supply and Controller service from the front side.

What we can do

*Project advise,Make the easy project design,easy for install and service

*Free on-line support

*We will send the setting file send with the goods. And also we will keep the Project file.

1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory 1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory

1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen FactoryPH4mm LED SMD Indoor Display Specification
Technicial Parameters
LED Parameters
No. Item Luminous Intensity Viewing Angle(H/V) Wavelength Test Condition
1 Red LED (Epistar DICE) 800-1000 140º/120º 620-630nm 25℃,20mA
2 Green LED(Epistar DICE) 1300~1500 140º/120º 520-535nm 25℃,20mA
3 Blue LED (Epistar DICE) 250~500 140º/120º 465-475nm 25℃,20mA
Module Specifications
1 Pixel Pitch 4mm 1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory
2 Pixel Configuration 3-in-1, SMD 2020
3 Module Resolution 64 X 32
4 Module Pixles 2048
5 Module Size 256mm X 128mm
6 Module power 5V3.6A 18W
Screen Parameters
1 Whole screen size 4.608mx3.072m = 14.15 sqm

1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory


1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory


1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory
2 Screen Resolution 1152 * 768
2 Cabinet quantity 18pcs*24pcs =432 pcs
3 Brightness ≥1000 mcd/㎡
4 Brightness(Max./Min.) 1.2:1
5 Driving Method 1/16 constant current
6 View Angle Horizontal 140° Vertical 120°
7 Optimal Viewing Distance 3M
8 Brightness Control Red,Green and Blue 256 Grade/Each
9 Refresh rate >1920HZ
10 Frame Frequency 60Hz
11 Input Voltage AC220V/50Hz or AC110V/60Hz
12 Defects Rate ≤0.00001
13 Power Consumption Max.: 800W/㎡
Average: 300W/㎡
14 Screen weight ≤20kg/㎡
15 MTBF >10,000 hours
16 Life span ≥100,000 hours
17 Module Display Brightness Uniformity <2%
18 Earth Leakage Current <3mA
19 Protective Grade IP33
20 Temperature-operating ﹣25℃～45℃
21 Humidity-operating 10%～95%
22 Controlling system LINSN
23 Operating System WIN7/WIN8/WIN10
Remarks:
1. Software and User’s manual in English included.
2. 30% Down Payment before Production, Balance before shippment
3. Lead time:15 working Days against down Payment
4. Two Years Maintain Replacement free.

Ship package

1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory

1920Hz Indoor LED Video Screen 4mm Pixel Pitches 1152 * 768 Screen Resolution Shenzhen Factory
