2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip
2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip
2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip
2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip
2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip
2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip
Specifications
Brand Name :
COREMAN
Model Number :
CM-IS-P2-512mm x 512mm
Certification :
CE,Rohs, FCC, CCC, UL, CAS，SASO
Place of Origin :
China
MOQ :
1pcs
Price :
310-360USD
Payment Terms :
T/T, Western Union, MoneyGram, L/C
Supply Ability :
50,000pcs/ month
Delivery Time :
15-20 days
Packaging Details :
flight case
Color :
RGB
Funciton :
Text,picture,animation, video
chip :
Silan,Epistar,opto,Nicha,Cree(optional)
Input :
AC 110/220V+-10%
LED cabinet size :
512mm x 512mm
LED chip :
COB SMD1515
Drive IC :
MBI5153,ICN5153 etc
Pixel pitch :
2mm
Refresh rate :
>3840Hz
Contrast rate :
4000:1
Description

256 x 256 hd led display panel , 512 x 512 480 x 480 500x500 p2 p2.87 p2.97 led rental display

P2 HD indoor led display screen , rental led panel cabinet feature:

1.Compact, Reliable and Easy to Service, the cabinet is architected to deliver what matters for quick installation and service.
2. Front Serviceable Module allows easy Maintenance.there is no need for maintenance channel , behind the screen. It can be attached to the wall to save time and space.
3.Front access design on cabinet, cabinets coming with fast lock, can install two cabinet within 5 second.
4.provides improved heat dissipation and faster, easier single-person handling during installation.
5.Slim and lightweight cabinet, it is easy to carry and take.
6.Popping-up protection mechanism, Edge proteciton at the bottom to prevent hitting with auotomatically telescopic design, safe and convenient for re-disassembly
7.Seamless splicing and assembling, the cabinet flatness spae is less than 0.1mm, no visible gap.
8. Double backup . Supporting Dual Control System one power and control card, Automatically Switch the Picture in any Led Screen when it occurs any problems to make sure a stable and reliable image.
9. End to end no delay, intelligent and dymamic low power consumption under low brightness and grey level.
10. Enegry saving, high refresh rate under low brightness and grey level.
11. Efficient and Reliable Remote Power.Remote Power Supply (RPS) that takes heat, depth, noise, weight, service points and electrical outlets away from the video wall and into a convenient
12. The display are available with single or dual power supplies, with the dual power supply options adding a level of redundancy.

What materials we use for the product?
1. Use high quality materials, Nicha Cree Silan Opto etc are optional.
2. Use good quality and stable components , like MBI, Samsung etc
3. Encapsulated LEDs from Nationstar , kinglight, KN-light are optional.
4. Famous power supply, Meanwell, Delta ,megmeet etc power supply for high-end market customer.


What we can do ?
1. Custom or standard design led module or cabinet to meet different customer requirement.
2. Certified product ,CCC, FCC CE -EMC, CE-LVD, Rohs,UL, CAS,SASO, etc for differen country and market.
3. Low price on the shipping ,fast delivery to save as much time as we can for customer.
4. 2-7 warranty according to customer situation and request.


What service we can provide
1. We will answer your inquiry with 24 hours via e-mail/ phone ,working 24 hours / 7 days.
2. We can provide the installation CAD drawing or struction for customer as negotiation.
3. We can send engineer to customer side to install the led display as cutomer request
4. We will provide maintenance for a lifetime and charge for the raw materials only.



Specification:

Pixel Pitch(W/H)mm 2mm
LED Size SMD1515
Pixel Density (dots/m2) 250,000
Cabinet Size (W*H*D)mm 512*512*65
Cabinet Resolution (W*H)dots 256*256
Cabinet Weight (kg/pcs) 6.5
IP Rating ( front/back) IP20-IP43
Brightness ≥1200cd/m2
Viewing Angle (H/V) 160°/160°
Viewing Distance ≥2m
Gray Scale 16bit
Max.Power Consumption (W/pcs) 272
Ave.PowerConsumption(W/pcs) 90
Refresh Rate ≥1920Hz(Max 3840Hz)
Environment Indoor
Control Mode Synchronous display with control PC by DVI /HDMI /DP
Support Input Composite,S-Vido,Component,VGA,DVI,HDMI,HD_SDI
Operation Power AC100~240 50/60HZ
Operating Temperature -20°C~55°C(work) , - 40°C~65°C(store)
Operating Humidity 10%~90% (work) , 10%~95% (store)
Operating Life >100,000hours
Specification might be slightly different based on different components
Indoor rental led display
P0.9375 600mm x 337.5mm
P1.25 600mm x 337.5mm
P1.33 600mm x 337.5mm
P1.5625 400mm x 300mm / 600mm x 337.5mm
P1.667 400mm x 300mm
P1.875 480mm x 480mm / 600mm x 337.5mm
P1.923 400mm x 300mm
P2 512mm x 512mm
P2.5 480mm x 480mm /640mm x 640mm
P3 576mm x 576mm
P4 512mm x 512mm
P5 640mm x 640mm / 960mm x 960mm
P6 576mm x 576mm
P10 640mm x 640mm / 960mm x 960mm
P2.97 500mm x 500mm / 500mm x 1000mm
P3.47 500mm x 500mm / 500mm x 1000mm
P3.91 500mm x 500mm / 500mm x 1000mm
P4.81 500mm x 500mm / 500mm x 1000mm
Outdoor rental led display
P3 576mm x 576mm
P3.91 500mm x 500mm / 500mm x 1000mm
P4.81 500mm x 500mm / 500mm x 1000mm
P5.95 500mm x 500mm / 500mm x 1000mm
P4 512mm x 512mm
P5 640mm x 640mm / 960mm x 960mm
P6 576mm x 576mm
P6.67 640mm x 640mm / 960mm x 960mm
P10 640mm x 640mm / 960mm x 960mm
P8 512mm x 512mm
P8 640mm x 640mm
P10 640mm x 640mm / 960mm x 960mm

2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip

2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip

2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip

2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip

2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip

2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip

2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip

Connection diagram

(Video processor is not must, it depends on the size of the display)



2mm Pixel Pitch P2 P2.87 Full HD Led Panel 512 X 512 256 X 256 By COB SMD1515 LED Chip


Application:

The led screen can be used as the indoor and outdoor stage LED display, dance floor, stadium LED display, sky backdrop curtain, fixing advertising LED display, showcase, Shopping center,stage , concert background, festival celebration , wedding, exhibition, meeting room, CCTV center ,airport , stadium games like football, basketball etc.etc. And it would be more convenient and fast .
