Specifications
Brand Name :
LETONE
Model Number :
LT583
Certification :
Hose execution SAE100R13 standard, GB/T10544-2013 standard
Place of Origin :
CHINA
MOQ :
100 Meter
Price :
1USD-20USD
Payment Terms :
T/T
Supply Ability :
Annual output of 10,000,000 meters
Delivery Time :
Within a month
Packaging Details :
Plastic stretch film or carton
Applications :
Suitable for conveying mineral oil, water-based hydraulic oil or water by hydraulic system such as coal mine hydraulic support and comprehensive coal mining unit
Tube :
black, oil resistant sythentic rubber
Reinforbraidcement :
4 layers of spiraled high tensile steel wire
Cover :
weather resistant sythentic rubber
Temperature range :
-40℃~+100℃ (-40°F~+212°F)
Brand :
LETONE
Standard :
EN856-4SP；GB/T10544-2013
Description
LT583 EN856-4SP 4 Wire Spiral Hydraulic Rubber Hose High Tensile Steel Wire
Application:Suitable for conveying mineral oil, water-based hydraulic oil or water by hydraulic system such as coal mine hydraulic support and comprehensive coal mining unit
Tube:black, oil resistant sythentic rubber
Reinforcement:4 layers of spiraled high tensile steel wire
Cover:weather resistant sythentic rubber
Temperature Range:-40℃~+100℃ (-40°F~+212°F)
Standard: EN856-4SP；GB/T10544-2013
Parameter
I.D. (mm) I.D. (in.) I.D. (mm) O.D.(mm) Max.W.P. Min. B.P. Min. B.R.
Min Max Max (MPa) (MPa) (mm)
10 3/8-4 9.7 10.5 24.0 70 210 180
13 1/2-4 12.7 13.5 27.5 57 172 210
16 5/8-4 15.7 16.6 31.0 53 160 260
19 3/4-4 18.7 19.8 35.5 46 140 280
22 7/8-4 21.7 22.8 39.5 41 124 320
25 1-4 24.7 25.8 42.5 35 112 360
32 1 1/4-4 31.6 32.6 50.5 32 84 460
38 1 1/2-4 37.7 38.8 57.5 25 75 560
45 1 3/4-4 44.7 45.8 64.5 21 64 640
51 2-4 50.5 52.0 70.5 21 64 720
10 3/8-6 9.7 10.5 26.0 80 240 180
13 1/2-6 12.7 13.5 30.5 72 216 210
16 5/8-6 15.7 16.6 34.5 70 204 260
19 3/4-6 18.7 19.8 38.5 60 180 280
22 7/8-6 21.7 22.8 42.5 53 160 320
25 1-6 24.7 25.8 45.5 50 152 360
32 1 1/4-6 31.6 32.6 53.5 41 124 460
38 1 1/2-6 37.7 38.8 60.5 36 108 560
45 1 3/4-6 44.7 45.8 67.5 32 96 640
51 2-6 50.5 52.0 74.0 32 96 720
