SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
SAE 100R12 4 Wire Spiral Super Artery Hose Hydraulic Rubber Hose Pipe
Specifications
Brand Name :
LETONE
Model Number :
LT581
Certification :
Hose execution SAE100R12 standard, GB/T10544-2013 standard
Place of Origin :
CHINA
MOQ :
100 Meter
Price :
1USD-20USD
Payment Terms :
T/T
Supply Ability :
Annual output of 10,000,000 meters
Delivery Time :
Within a month
Packaging Details :
Plastic stretch film or carton
Applications :
Suitable for using oil base hydraulic oil, is suitable for the harsh conditions of high temperature and medium pressure hose
Tube :
The hose consists of a heat-resistant synthetic rubber inner layer
Reinforbraidcement :
Four-layer steel wire winding layer
Cover :
Oil-resistant and weather resistant synthetic rubber The outer rubber layer is composed
Temperature range :
40 ℃ ~ + 121 ℃ (- 40 ° F ~ + 250 ° F)
Brand :
LETONE
Standard :
Hose execution SAE100R12 standard, GB/T10544-2013 standard
Description
LT581 SAE 100R12 4 Wire Spiral High Pressure Hydraulic Rubber Hose
Application:Suitable for using oil base hydraulic oil, is suitable for the harsh conditions of high temperature and medium pressure hose
Tube :The hose consists of a heat-resistant synthetic rubber inner layer
Reinforcement: Four-layer steel wire winding layer
Cover:Oil-resistant and weather resistant synthetic rubber The outer rubber layer is composed
Temperature range :40 ℃ ~ + 121 ℃ (- 40 ° F ~ + 250 ° F)
Standard:Hose execution SAE100R12 standard, GB/T10544-2013 standard
Parameter
I.D. (mm) I.D. (in.) I.D. (mm) O.D.(mm) Max.W.P. Min. B.P. Min. B.R.
Min Max Max (MPa) (MPa) (mm)
10 3/8 9.3 10.1 21.0 28 112 125
13 1/2 12.3 13.5 24.6 28 112 180
16 5/8 15.5 16.7 28.2 28 112 200
19 3/4 18.6 19.8 31.5 28 112 240
25 1 25.0 26.4 39.2 28 112 300
32 1 1/4 31.4 33.0 48.6 21 84 420
38 1 1/2 37.7 39.3 55.0 17.5 70 500
51 2 50.8 52.0 68.3 17.5 70 640
