Product Description:
48V 300Ah 15Kwh Wall Lithium Battery Energy Storage
48V 300ah 15kwh Solar System Powered Storage Wall Lithium Battery Energy Storage
Our solar system-powered storage wall lithium battery energy storage system is a large-capacity battery solution designed for storing and utilizing solar energy. Here are some key points about this type of energy storage system:
- 51.2V 48V Lithium Ion Battery Pack
- 15kWh capacity for long-lasting power supply
- Rack-mounted design for easy installation and scalability up to 16 units
- IP20 protection level ensures safety from dust and moisture
- Overcharge, overdischarge, overcurrent, short circuit, and temperature protection for reliable operation
- RS485/CAN communication interface for convenient monitoring and control
- Max. discharge DC Power: 10000W with ability to connect more than 2 units in parallel for increased output
- Lightweight at about 38KG for easy handling
- Operating temperature range of 0℃~50℃ for stable performance in various environments
When considering a 48V 300Ah, 15kWh solar system-powered storage wall lithium battery energy storage system, it is important to evaluate factors such as the system's efficiency, warranty, safety features, and compatibility with your specific solar setup. Professional installation and consultation may be necessary for proper integration and optimal performance.
Technical Parameters:
| Model Number | TS2400 | TK2000 | TK3000 | TS5000 | TK7200 | TK10000 | | Norminal Battery Energy | 2.40KWH | 2.56KWH | 3.84KWH | 5.12KWH | 7.68KWH | 10.24KWH | | Norminal Capacity | 50Ah | 50Ah | 75Ah | 100Ah | 150Ah | 200Ah | | Norminal Voltage | 48V | 51.2V | 51.2V | 51.2V | 51.2V | 51.2V | | Dimensions (mm) | 2U 482x410x89 | 3U 482x350x132 | 3U 482x350x132 | 4U 482x400x177 | 5U 482x430x222 | 6U 482x500x280 | | Internal Resistance | ≤30mΩ | | Cycle Life | >6000 | | Months Self Discharge | <3% | | Charge Data | | | DC Normal Charge Voltage | 58.4±1Vdc | | Charge Mode | 0.2C to 58.4V, then 58.4V charge current to 0.02C (CC/CV) | | Recommended Charger Current | <20A | | Allowed Max.Charge Current | 25A | 50A | | Charge Cut-off Voltage | 54.7±1Vdc | 58.4±1Vdc | | Discharge Data | | | Continuous Discharge Current | 25A | 50A | | Allowed Max. discharge current | 50A | 100A | | Discharge cut-off voltage | 38V | 40V | | Working Condition | | | Charge Temperature | 0'C to 45'C (32°F to 113°F) | | Discharge Temperature | -20° C to 60°C(4°F to140°F) | | Storage Temperature | 0°C to 40°C(32°F to 104°F) | | Enclosure Protection Level | IP54 | | Mechanical Data | | | Cell&Capacity | 25AH&50AH | 25AH&75AH | 50AH&100AH | 50AH&150AH | 50AH&100AH | | Case material | Iron Rack Mount Case | |
Support max. 4 parallels
If without master control, it support max. 4 parallels for highest 20.48Kwh battery system; If with standard master controls, it can be paralleled and serialed with more batteries.
Applications:
Support and Services:
Rack Mount Lithium Battery Technical Support and Service
Professional team provides technical support and services
Highly trained professionals
Provides technical support and services for Rack Mount Lithium Battery
Specializes in Lithium Battery products
Assistance with all components
Assistance with battery cells, connectors, cables, and racks
Technicians have experience in all aspects of the product
Can help with any technical issues
Range of services
Dedicated to providing the best customer service and technical support possible
Contact information
If you have any questions or would like to schedule a service appointment, please contact us.
Packing and Shipping:
To ensure the safe and secure transportation of stackable lithium batteries, follow these steps:
- Package the battery securely in a container. Use a sturdy cardboard box or hard plastic box, and seal the container tightly.
- Label the container with the product name, weight, and serial number. This will help to identify the battery and ensure that it is handled correctly during shipping.
- Place the container in a protective bag and seal it with a zip tie. This will provide an extra layer of protection for the battery.
- Place the package in a sturdy cardboard box and seal it with tape. Make sure that the box is large enough to accommodate the package with sufficient padding around all sides.
- Clearly label the package with the shipping address and other shipping information. This will help to ensure that the package is delivered to the correct destination.
- Securely wrap the package in bubble wrap or other protective material. This will help to protect the battery from damage during shipping.
- Ship the package via a reputable shipping carrier. Choose a shipping carrier that has experience in shipping hazardous materials.
Highlights:
Safe and protective packaging
Clear labeling
Reputable shipping carrier
By following these steps, businesses can help to reduce the risk of damage to stackable lithium batteries during shipping.
FAQ:
Q: How can I get a quote?
A: We typically respond to quote requests within 24 hours, except on weekends and holidays. If you need a quote urgently, please email us or contact us in another way so that we can prioritize your request.
Q: Can I order samples?
A: Yes, you can. Please feel free to contact us to place an order for samples.
Q: What is your lead time?
A: The lead time depends on the order quantity and the time of year when the order is placed. For small orders, we can usually ship within 7-15 days. For large orders, the lead time is typically around 30 days.
Q: What is the shipping method?
A: We can ship orders by sea, air, or express (EMS, UPS, DHL, TNT, FedEx, etc.). Please confirm your preferred shipping method with us before placing an order.
Q: What certifications does the product have?
A: The product has CE, TUV, RoHS, and UN38.3 certifications.
Q: What is the minimum order quantity (MOQ)?
A: There is no MOQ.
Q: Do you offer customization?
A: Yes, we offer customization for our products.
Battery Functions
