TE908 7.8ton 3.3L Displacement Mini Crawler Excavator Road Construction Machine
TE908 7.8ton 3.3L Displacement Mini Crawler Excavator Road Construction Machine
TE908 7.8ton 3.3L Displacement Mini Crawler Excavator Road Construction Machine
TE908 7.8ton 3.3L Displacement Mini Crawler Excavator Road Construction Machine
Specifications
Brand Name :
LGMC
Model Number :
TE908
Certification :
ORIGINAL or OEM
Place of Origin :
China
MOQ :
1PC
Price :
Negotiated price
Payment Terms :
T/T, Western Union, L/C
Supply Ability :
100 pieces per month
Delivery Time :
5-15days
Packaging Details :
Container
Operating Weight :
7.8t
Engine :
CUMMINS B3.3
Blade :
2300mm×386.5mm
Boom :
3.76m
Arm :
1.65m
Bucket :
0.32m3
Description

LGMC TE908 Hydraulic Crawler Excavator CUMMINS B3.3 Engine Four-Cylinder In Line Turbocharged Water Cooling

Product Description:

· Place of Origin: China

· Model Number: TE908

· Name: MINI EXCAVATOR

· Warranty: 3 Months

· Delivery: 3-5 Working Days

· Stock quantity: available

Packaging & Delivery :


Packaging Details: Container

Port: QINGDAO
Lead Time: Shipped in 10day after payment

TE908 Hydraulic Crawler Excavator’s Operating Weight is 7.8t, equipped with CUMMINS B3.3 Engine, with Boom 3.76m, Arm 1.65m, Bucket 0.32m3, and Blade 2300mm×386.5mm.

Notice: Only after getting the permission of our company that the optional or special parts can be installed on the machine.

TE908 Hydraulic Crawler Excavator

Technical Specifications

Engine Travel System
Model CUMMINS B3.3 Travel motors JEIL, Korea; Variable axial piston motor
Type Four-cylinder in line, turbocharged, water cooling Support roller quantities 2×6
Carrier roller quantities 2×1
No. of cylinder 4 Travel shoes 2×40
Bore and stroke 95mm×115mm Travel speed 3.14 /5.26km/h
Displacement 3.3L Drawbar pulling force 67.7kN
Power output 60kW/2200rpm Grade ability 70% (35°)
Ground clearance 362mm
Hydraulic System Cab ＆ Control
Pump KAWASAKI, Japan Cab All-weather, sound-suppressed Cab and equipped with a heavy, insulated Floor Mat; Front Window can be opened and slid; 6-direction adjustable Seat; LED display, Automatic monitoring, display and warning; cool & hot Air Conditioner
Type variable double–piston pump
Max. discharge flow 2×74.8L/min
Max. discharge pressure
Boom, arm and bucket 27.5MPa Control

Two hand levers and two foot pedals for travel Two hand levers for excavating and swing;

Electric rotary-type engine throttle
Travel circuit 27.5MPa
Swing circuit 23.5MPa
Control circuit 3.9MPa Boom, Arm ＆ Bucket
Pilot control pump Gear type Boom cylinder 115mm×65mm×864mm
Main control valve Negative flow control Arm cylinder 100mm×60mm×867mm
Oil cooler Air cooled type Bucket cylinder 90mm×55mm×710mm
Swing System Refilling Capacities＆lubrications
Swing motor KYB, Japan Fuel tank 230L
Swing motor type Axial-piston motor Cooling system 15L
Brake Hydraulic oil released Engine oil 13L
Parking brake Hydraulic disc brake Hydraulic oil tank 110L Tank oil level
Swing speed 11.2r/min 175L Hydraulic system
Bucket
Type Backhoe bucket
Bucket capacity 0.32m3 (SAE)
Bucket width 820mm
Arm Type
A Max. digging depth 6569mm
B Max. dumping height 4535mm
C Max. digging height 4006mm
D Max. vertical digging depth 3581mm
E Max. Depth cut for 2440m(8')Level Bottom 3656mm
F Max. digging distance 6448mm
G Max. digging radius at ground level 6293mm
H Min. swing radius of work equipment 2382mm
Digging Force (ISO6015) Unit: kN
Arm length 1650mm
Bucket digging force 53.6kN
Arm digging force 39.9kN
Arm Type 1650mm
A Overall length 6224mm I Tread 2285mm
B Ground contact length (Transportation) 3905mm J Track length 2933mm
C Overall height(to top of boom) 2635mm K Track gauge 1850mm
D Overall width 2310mm L Track width 2300mm
E Overall height(to top of cab) 2633mm M Shoe width 450mm
F Counter weight ground clearance 817mm O Bonnet height 1825mm
G Ground clearance 362mm P Revolving frame width 2292mm
H Tail swing radius 1750mm Q Distance from swivel center to tail 1750mm
Operating Weight and Ground Pressure
Operating weight includes basic machine (with boom 3.76m, arm 1.65m, bucket 0.32m3, and blade 2300mm×386.5mm)
Shoe width 450mm
Overall width 2300mm
Ground pressure 33.7KPa
Operating weight 7800kg

TE908 7.8ton 3.3L Displacement Mini Crawler Excavator Road Construction Machine

Our advantages :

1. We can help buyers design specific products or produce products according to buyers' design.
2. Small order acceptable.
3. Competitive price be offered.
4. Inquiry or question be answered within 12 hours.
5. Best possible after-sales service.
6. We can print logo according to buyers' requirement.
7. Stock an extensive range of spare parts.
8. Favourable geographical location.
9. Flexible pricing, offers discount and deferred payment for wholesale buyers.
10. Timely delivery.

FAQ:

Q1. Could you custom products?
A: We can manufacture it according to your drawings or samples.
Q2. What's your payment terms.
A: By T/T or Western Union, 100% in advance. ( large orders can be negociated)
Q3. What is your terms of delivery?
A: EXW, FOB, CFR, CIF, DDU.
Q4. How about your delivery time?
A: 1-3 working days in general, and 7-10 days for large orders.
Q5. How can you guarantee the quality?
A: One year's warranty against B/L date.If You meet with quality problem, we promise to responsible for it.
Q6: Can we buy 1 pc of each item for quality testing?
A: Yes, we understand quality test is important and we are glad to send 1pc for quality testing.
