Quick Detail:
1- High energy density: 208WH/kg
2- Support continuous discharge rate of 2C and charge rate of 1C
3- Excelllent cell consistency performance
4- widely applied for flashlight, power tools, UPS, Lead-acid replacement battery, solar systems, energy storage, power station, telecom station, UPS, solar wind power generation, ships, yachts, railway, electric motorcycle, golf cart, golf trolley, robots, medical and military devices. etc
5- long cycle of 1000 times

Cell Characteristics Curves

• Specifications:

• Nominal voltage	3.7V
  Nominal capacity	5000mAh
  Minimum capacity	4950mah
  Cell type	NMC
  Resistance	＜20mΩ
  Discharging cut-off voltage	2.75V
  Charging upper limit voltage	4.25V
  Max. charging current	1C
  Standard discharge current	1C
  Max. continuous discharging current	2C
  Dimensions	Diameter ≤26.3mm
  	Height: 65.2±0.3mm
  Weight	approx. 95g
  Operation temperature	0~45
  	-20~60℃
  Storage temperature	-20~45℃

•

Competitive Advantages:
Company advantages:
1-Good Quality Management:
Our Pack production base for mass order have passed TS16949 Quality System, ISO14001 Environmental System and OHSAS18001 system certifications. And we have passed the test of the National Motor Vehicle Product Quality Supervision and Inspection Center. We always do daily production as per these systems.
2-Advanced hardware and software facilities
We established high-precision three-coordinate measuring machines, projectors, universal material tensile machines, and other measuring instruments to ensure the effective quality data.
3-Technical advantages:
Our technical team are all from China famous electric vehicle manufacturers. They all have more than 10 years' industry experiences. They have excellent R&D abilities. We also have the ability to develop BMS by ourselves.

Product advantages:
Our products are of high quality because
The cells we use are domestic high-quality cellsfrom China big cell manufacturers or imported cells from Sumsang, Panasonic.LG, etc .
BMS are realiable. BMS within 24S, we develop by ourselves. BMS above 24S, we purchase from China top 3 BMS manufacturers.
Advanced battery pack assembly technologies ensures the finished battery packs are of high quality.
