FEATURES:
1.Off-road vehicles
Electrical Parameters | |
Rated Voltage | 12.8V |
Nominal Capacity | 150Ah |
Nominal Energy | 1920Wh |
Internal Resistance | ≤30mΩ |
Efficiency | ≥0.98 |
Cycle Life | >4000cycles @0.5C,80% DOD |
Self Discharge | <5% per Month |
Max. Modules in Series,Parallel | 4S/1P |
Mechanical Parameters | |
Dimension(LxWxH) | 615x445x60mm |
Dimension((LxWxH) | 24.12x 17.52x 2.36 |
Weight | 25Kg |
Terminal Type | Reference connector parameters |
Battery Housing | SPCC |
Housing Protection | IP30 |
Cell Type-Chemistry | LiFePO4 Cell |
Communication | Bluetooth |
Charge Parameters | |
Charge Method | CC-CV |
Charge Voltage | 14.2~14.6V |
Recommended Float Voltage | 13.3~13.4V@100% |
Recommended Charge Current | / |
Maximum Charge Current | 150A |
BMS Charge Cut-off Voltage | 14.8V |
Discharge Parameters | |
Continuous Discharge Current | 150A |
Pulse Discharge Current | 230A(<1S) |
Recommended Volt. Disconnect | 10V |
BMS Discharge Cut-off Voltage | 10V |
Reconnect Voltage | 10.8V |
Short Circuit Protection | 300-800us |
Connector | |
Anderson 50A(Blue) | Alternator,DC11.5~16V,Max40A |
Anderson 50A(Red) | Solar,DC11.5~DC50V,Max40A |
Anderson 175A(Grey) | DC10~DC14.6V,Max150A |
Anderson 50A(Grey) | DC10~DC14.6V,Max50A |
CigaSocketr | DC10~DC14.6V,Max10A |
Anderson 175A(Grey) | DC10~DC14.6V,Max10A |
USB-A+USB-C | 18W+65W |
USB-Cx2 | 45W |
2P Wiring Terminal | IGNITION |
4P Wiring Terminal | Display screen |
Temperature Parameters | |
Discharge Temperature | -20℃ to 60℃ |
Charge Temperature | 0℃ to 55℃ |
Storage Temperature | -20℃ to 60℃ |
BMS High Temperature Cut-off | 65℃ |
Hefei ECOLTO Energy is a China leading manufacturer of highquality lithium batteries, From cells to automated modules to PACK production lines, we provide you with high-quality products. Wehave our own intellectual property and full-automatic equipment, to meet different customization needs, and provide you with a onestop service.
We have our own production workshop. We develop and produce everything from battery cells to Pack assembly. We have been in this industry for more than ten years. We serve every customer with a reliable, trustworthy and pragmatic attitude.
Q: Do you provide free sample?
A: Yes, a few pcs free sample can be provided, but freight will be charged
Q: what is the warranty?
A: one year
Q: What is your payment term?
A: T/T,L/C
Q: do you accepte OEM order?
A: Yes, you can print yourself logo, also we can provide the design of outlook for your special battery pack
Q: How many cells you can produce per month?
A: 1.8million
Q: What is the mode of transport?
A: usually by sea
Q: Which certificates do you have
A: We have un38.3,MSDS...etc.
