Off Grid Solar Power Storage System 50ah 48V Lifepo4 Battery Pack
Off Grid Solar Power Storage System 50ah 48V Lifepo4 Battery Pack
Specifications
Brand Name :
Ecolite
Model Number :
48v 50Ah
Certification :
UN38.3 MSDS CE
Place of Origin :
China
MOQ :
1000pcs
Price :
Inquiry
Payment Terms :
L/C, T/T
Supply Ability :
5000 units/month
Delivery Time :
5-8 work days
Packaging Details :
Carton Pallet Container
Nominal Voltage :
51.2V
Rated Capacity :
50Ah
Energy :
2560Wh
Resistance :
≤48mΩ
Efficiency :
0.99
Cycle Life :
>4000cycles
Max. Modules in Series/Parallel :
16S/1P
Weight :
28.5kg
Terminal Type :
SLPRBPSR、SLPRBPSB
Battery Housing :
Matel
Housing Protection :
IP40
Cell Type-Chemistry :
LiFePO4 Cell
SOC Display(Optional) :
LED
Communication Mode(Optional) :
CAN、RS485
Description

Solar Storage System Off Grid Power LFP Battery Pack 48v 50Ah For Home Application

Electrical Parameters
Nominal Voltage 51.2V
Rated Capacity 50Ah
Energy 2560Wh
Resistance ≤48mΩ
Efficiency 0.99
Cycle Life >4000cycles
Max. Modules in Series/Parallel 16S/1P
Mechanical Parameters
Dimension(LxDxH) 483x303x188mm
19.02x11.93x7.40
Weight 28.5kg
Terminal Type SLPRBPSR,SLPRBPSB
Battery Housing Matel
Housing Protection IP40
Cell Type-Chemistry LiFePO4 Cell
SOC Display(Optional) LED
Communication Mode(Optional) CAN,RS485

Discharge Parameters
Standard Discharge Current 50A
Pulse Discharge Current 100A(<3S)
Recommended Volt. Disconnect 40V
BMS Discharge Cut-off Voltage 38.4V
Reconnect Voltage 46.4V
Short Circuit Protection 200-500uS

Charge Parameters
Charge Method CC-CV
Charge Voltage 57.6-58.4V
Recommended Float Voltage 56V
Recommended Charge Current 25A
Maximum Charge Current 50A
BMs Charge Cut-off Voltage 59.2V

Temperature Parameters
Discharge Temperature -30to 60℃
Charge Temperature 0 to 60℃
Storage Temperature -20 to 35℃
BMS High Temperature Cut-off 70 ℃

Off grid solar system, UTL Off-Grid Solar System for Home Price with Detail, Best Off-Grid Solar Systems in 2022, Off-grid Solar Kits

Q :Do you provide free sample ?
A: Yes, a few pcs free sample can be provided, but freight will be charged

Q: what is the warranty?
A: one year

Q:What is your payment term ?
A: T/T,L/C

Q:do you accepte OEM order ?
A: Yes,you can print yourself logo, also we can provide the design of outlook for your special battery pack

Q :How many cells you can produce per month?
A: 1.8million

Q :What is the mode of transport?
A: usually by sea

Q:Which certificates do you have
A:We have un38.3,MSDS…etc.
