IP65 48V LiFePO4 Battery For Golf Cart Marine Boat With CAN RS485
IP65 48V LiFePO4 Battery For Golf Cart Marine Boat With CAN RS485
Specifications
Brand Name :
Huaxing
Model Number :
HX48100-G
Certification :
CE
Place of Origin :
China
MOQ :
1
Price :
Negotiation
Supply Ability :
50 pks per day
Delivery Time :
20-30 days
Packaging Details :
Wood case package
Material :
LiFePO4/Grahpite
Nominal Voltage :
51.2V
Nominal Capacity :
100AH
Max charge voltage :
58.4V
Cut off voltage :
40V
Light weight :
~60kg
Steel case dimension :
500*343*256.5
Long life span :
2000 cycles
Customized Capacity :
100-400Ah
Warranty :
2 years
Description

IP65 48V LiFePO4 Battery For Golf Cart Marine Boat With CAN RS485

Lithium Ion Battery 51.2V 100AH For Golf Cart Marine Boat With CAN / RS485 IP65

48V 100AH LiFePo4 battery features

● More than 10 years of life cycles.

● Light-weight: Lightweight design, packed with aluminum plate and plastic components.

● They are designed to replace the lead-acid battery, which are available for drop-in replacement

● Insulation: Perfect electrical insulation, both inside and outside.

● Performance: Good heat conductivity, safety performance.

● No more maintenance.

● IP65

48V 100AH Deep cycle Lithium ion battery specification

No. Item General Parameter
1 Model HX48100
2 Standard Capacity 100AH
3 Rated Voltage 51.2V
4 Max Charge Voltage 58.4V
5 Discharge Cut Off Voltage 40V
6 Standard Charge Current 50A
7 Max Continuous Discharge Current 100A
8 Peak Instant Discharge Current 200Ah with 5S
9 Dimension(Steel Case) 500*343*256.5
10 Total weight(Approx.) 60kg
11 Operate Temperature -20°C~60°C
12 Built-in BMS YES
13 Cycle Times 2000 cycles
14 IP Grade IP65

48V 100AH Lithium ion battery software BMS specification

Item Content Criterion
Charge and Discharge Port Shared
Communication None
Parallel Connection Max 2 pcs
Serial Connection None
Normal Current Charge Current ≤100A
Discharge Current ≤100A
Over charge Protection Over charge detection voltage 3.75±0.05V
Over charge detection delay time ~1000mS
Over charge release voltage 3.55±0.05V
Over charge release condition Cut off charger
Maximum charge voltage 3.65±0.05V
Over discharge protection Over discharge detection voltage 2.20V±0.10V
Over discharge detection delay time 200ms
Over discharge release voltage 2.4V±0.10V
Discharge over current protection Discharge over current detection current 330±30A
Discharge over current detection delay time ~100±50ms
Discharge over current release condition Cut load
Short circuit protection YES

Main Applications:

Our LiFePO4 battery pack for golf carts outlasts the competition in performance and precision. These 36V, 48 V and 72V lithium batteries are suitable for today’s golf cart market. They offer exceptional speed, acceleration, and value for your golf cart, utility vehicle, AGV, and more.

IP65 48V LiFePO4 Battery For Golf Cart Marine Boat With CAN RS485

Products Picture:

IP65 48V LiFePO4 Battery For Golf Cart Marine Boat With CAN RS485

Company Profile

Shenzhen Huaxing New Energy Technology Co.,Ltd is R&D production and sales of 32700 LiFePo4 cells and battery pack.

Our company passed ISO9001:2015 and iSO14001:2015 and ISO45001:2018

Our 32700 LFP cell passed UL1642/IEC62619/IEC61960/IEC62133/CE/PSE/BIS/Rohs/UN38.8 and MSDS.

IP65 48V LiFePO4 Battery For Golf Cart Marine Boat With CAN RS485

IP65 48V LiFePO4 Battery For Golf Cart Marine Boat With CAN RS485

Customized as per customer requirement

1. The battery pack can be applied for electric vehicle factory new project, also suitable for replacing lead-acid battery project . Dimension and interface, battery cell material can be customized for EV factory customers.

2. Professional battery design. Our engineer’s team can customize the best solution considering mechanical & electrical concepts.

3. Sample order available. Factories or wholesalers can place sample orders to test our battery performance on the electric vehicle first and then place the batch mass production order.
