5-20kwh Low-pressure Rack-type LFP Home Energy Storage with CAN/RS485 Communication
5-20kwh Low-pressure Rack-type LFP Home Energy Storage with CAN/RS485 Communication
5-20kwh Low-pressure Rack-type LFP Home Energy Storage with CAN/RS485 Communication
5-20kwh Low-pressure Rack-type LFP Home Energy Storage with CAN/RS485 Communication
Specifications
Brand Name :
HUAXING
Model Number :
5-20kwh
Certification :
UN38.3
Place of Origin :
China
MOQ :
1
Price :
Customized price
Payment Terms :
T/T, L/C
Packaging Details :
543*505*880mm/218kg
Shape :
rack-mounted
Battery Nominal Energy :
5.12kwh/10.24kwh/15.36kwh/20.48kwh
Rate Voltage :
51.2V
Rated capacity :
100Ah/200Ah/300Ah/400Ah
Protection Rating :
IP21
Communication :
CAN/RS485
Operating temperature :
－20°C~＋55°C
Rate current :
0.5C
Dimension (W*D*H) :
460*440*197mm/543*505*440mm/543*505*660mm//543*505*880mm
Wight :
50kg/118kg/168kg/218kg
Description

5-20kwh Single-phase low-pressure rack-type LFP home energy storage

product model : 5.12kwh10.24kwh 15.36kwh 20.48kwh power

Product presentation:

Single-phase low-voltage rack-type home energy storage, adoptedHigh quality lithium iron phosphate battery (LFP), excellent performance,Safe, reliable and durable; Rack mounted, easy to installAnd maintenance; Intelligent air cooling can effectively reduce the temperature and raise the systemSystem effectiveness; With CAN/RS485 communication interface, supportVarious brands of inverters.

Product feature:

1. Built-in CAN, RS485 communication interface,Compatible with many mainstream inverters in the market.

2. Flexible capacity up to 20.48kWh,Easy maintenance and troubleshooting.

3. Built-in high-quality lithium iron phosphate battery,High stability, long cycle life.

4. Easy installation, no need for on-site assembly.On demand, fast and easy.

System Parameters

Product Model BATT-LS-5-A
System parameter
Cell Technology LFP(LifePO4)
Battery Nominal Energy 5.12Kwh
Rated Capacity 100Ah
Rating Power 2560W
Rated Voltage 51.2V
Operating Voltage Range 44.8-58.4V
Rated charge/discharge current 50A
Maximum charge/discharge current 100A
Peak discharge current(30s) 200A
Number of cycles ≥4000(at 80%DOD,0.5C,25°C)
General parameters
Dimension(W*D*H)

550x440x135mm

( 21.6x17.3x5.3 inch)
Weight 44kg(97 lb)
Protection Rating IP20
Cooling Natural cooling
Operating Temperature Charging:0°C~＋55°C；Discharging:－20°C~＋55°C
Relative humidity 10%-90%RH
Installation Rack mount/Cabinet
Communication CAN/RS485
Demonstate SOC Status Indicator/LED Indicator
Scalability Max.31 in parallel(155kwh)
Standards & Certifications
Transportation UN38.3

Company Information

Hunan Huaxing New Energy Technology Co., Ltd is a high quality Lithium Ion
Battery company, integrating R&D, manufacturing and sales, providing comprehensive solutions for any application.

-1000 Staff
-50,000 square meters of workshops
-3GWh annual production capacity
-300 million dollars annual turnover

Quality Management System: ISO 9001:2015, ISO 14001:2015, ISO 45001:2018
Product Safety and Performance Certificate: UL1642, IEC62619:2017, IEC62133:2017,
IEC61960:2011, CE, BIS, PSE, ROHS, UN38.3, MSDS
