Customizable Steel Electric Scissor Lifting Platform with PLC Control System
Customizable Steel Electric Scissor Lifting Platform with PLC Control System
Customizable Steel Electric Scissor Lifting Platform with PLC Control System
Customizable Steel Electric Scissor Lifting Platform with PLC Control System
Specifications
Brand Name :
Eternalwin
Model Number :
EW
Place of Origin :
China
Certification :
CE/SGS/BV
MOQ :
1
Price :
negotiable
Packaging Details :
Wooden case
Delivery Time :
30 work days
Payment Terms :
T/T, L/C
Platform Size :
Customized
Control System :
PLC
Material :
Steel
Power Supply :
AC/DC
Lifting Speed :
Customized
Platform Surface :
Anti-slip
Lifting Height :
Customized
Warranty :
1 Year
Description

Product Description:

Vertical Lift Mechanism: The mast lifts vertically, providing stable elevation for workers and tools.
Self-Propelled: The unit can move on its own power, allowing easy repositioning without needing external assistance.
Compact Design: Typically compact, making them ideal for confined spaces.
Electric or Hydraulic Operation: They can be powered by electric motors or hydraulic systems.
Safe and Stable: Equipped with stabilizers or outriggers to ensure safety and stability at heights.
Platform Capacity: They can support varying capacities, depending on the model, generally suitable for one or two workers and their tools.
Ease of Operation: Often designed for ease of use, with straightforward controls for lifting and movement.

Customizable Steel Electric Scissor Lifting Platform with PLC Control SystemCustomizable Steel Electric Scissor Lifting Platform with PLC Control SystemCustomizable Steel Electric Scissor Lifting Platform with PLC Control System

Features:

  • Automatic brake system
  • Emergency lowering system
  • Emergency stop button
  • Cylinder holding valve
  • Intelligent onboard diagnostic system
  • Non-marking tyres
  • Automatic pothole protection
  • Proportional controls
  • Descent and tilt alarm
  • Battery charger indicator

Technical Parameters:

Model AMWP6-6100
Rated capacity 159kg
Outreach working platform load 114kg
Max. Working height 8m
Max.Platform height 6m
Overall lenght 1.36m
Overall width 0.82m
Overall height 1.98m
Platform size 1.3m*0.7m*1.1m
Platform outreach size 0.51m
Max.ground clearance(stowed) 0.1m
Max.ground clearance(raising) 0.023m
Wheelbase 1.04m
Min.turning radius(inner tyre) 0.3m
Min.turning radus (outer tyre) 1.8m
Lift motor/Drive motor 1.3KW/0.5kw
Drive speed(stowed) 4km/h
Drive speed (raising) 1.1km/h
Lift/down speed 52/53 sec
Battery 2×12V/100Ah
Charge 24v/15A
Max. Gradeability 25%
Max.Working angle 1.5°
Tyre Φ305*100mm
Total weight 1060kg

Applications:

Aluminum alloy hydraulic lifting platform used high strength quality aluminum alloy materials,having advantages such as good-looking appearance,small size,light weight,steady moving,safety and so on.It's widely used in factories,hotels,restaurants,stations,theaters,exhibition centers,etc.And it's the best choice to maintain equipment,paint and decorate,change bulbs and electric devices and so on.

FAQ:

Q: What is the brand name of this electric lifting platform?

A: The brand name of this electric lifting platform is Eternalwin.

Q: What is the model number of this electric lifting platform?

A: The model number of this electric lifting platform is EW.

Q: Where is this electric lifting platform made?

A: This electric lifting platform is made in China.

Q: What certifications does this electric lifting platform have?

A: This electric lifting platform has CE, SGS, and BV certifications.

Q: What is the minimum order quantity for this electric lifting platform?

A: The minimum order quantity for this electric lifting platform is 1.

Q: Is the price of this electric lifting platform negotiable?

A: Yes, the price of this electric lifting platform is negotiable.

Q: What are the packaging details for this electric lifting platform?

A: The packaging details for this electric lifting platform are wooden case.

Q: What is the delivery time for this electric lifting platform?

A: The delivery time for this electric lifting platform is 30 work days.

Q: What are the payment terms for this electric lifting platform?

A: The payment terms for this electric lifting platform are T/T and L/C.
