RT8-S1 Modular Timing Relays AC/DC12-240V
RT8-S1 Modular Timing Relays AC/DC12-240V
RT8-S1 Modular Timing Relays AC/DC12-240V
RT8-S1 Modular Timing Relays AC/DC12-240V
RT8-S1 Modular Timing Relays AC/DC12-240V
RT8-S1 Modular Timing Relays AC/DC12-240V
Specifications
Brand Name :
OEM/Fenigal
Model Number :
RT8-S1/S2
Certification :
CE,CCC etc.
Place of Origin :
China
MOQ :
Negotiable
Price :
USD7~USD8/unit
Payment Terms :
T/T, Western Union
Supply Ability :
10,000pcs/month
Delivery Time :
5-8 working days or bulk order negotiate
Packaging Details :
Standard export carton
Product Name :
DIN rail mount Time Relay
Type :
Time Delay Relay
Control Volt :
DC/AC24, AC230V
Acceossories :
Available
Description

RT8-S1 AC/DC12-240V Adjustable Protective Time Relay Cycler 12v 24v 48 volt DC Relay Price

General

Applications
-It is used for regular room ventilation, cyclic dehumidifi cation, light control,
circulating pumps, noon signs, etc.


Function Features
-2 time functions:
-Cycler beginning with pulse
-Cycler beginning with pause
-Function choice is done by an external jumper of terminals S-A1.
-Time scale 0.1 s - 100 days devided into 10 time ranges:
(0.1 s - 1 s / 1 s - 10 s / 0.1 min - 1 min / 1 min - 10 min / 0.1 hrs - 1 h
/ 1 hrs - 10 hrs / 0.1 day - 1 day /1 day - 10 days /3 days - 30 days /
10 days - 100 days).
-Relay status is indicated by LED.
-1-MODULE,DIN rail mounting.

Electrical features

Model NO GRT8-S1 OR GRT8-S2
Function Asymmetric Cycler Timer Relay
Voltage Range AC230V (A230) OR AC/DC12V-240V (W240)
Output 1 SPDT OR 2 SPDT
Supply Terminals A1-A2
Supply Voltage Tolerance -15% +10%
Time Setting Potentionmeter
Supply Indication Green LED
Output Indication Red LED
Rated Frequency 50/60HZ
Rated Current 16A/AC1
Protection Degree IP40 for front Panel / IP20 for Terminals
Weight/pcs 0.1KG/PCS
Standard EN 61812-1,IEC60947-5-1
Certifications CE CB CCC TUV
Warranty/guarantee 18months
MOQ 1PCS

RT8-S1 Modular Timing Relays AC/DC12-240V

RT8-S1 Modular Timing Relays AC/DC12-240V

RT8-S1 Modular Timing Relays AC/DC12-240V
