Class 1 Switch Type Power Surge Protective Device SDZ100-50
Class 1 Switch Type Power Surge Protective Device SDZ100-50
Specifications
Brand Name :
Xi'an Shendian
Model Number :
SDZ-100-50
Certification :
IEC 61643-311
Place of Origin :
China
MOQ :
1 pc.
Price :
To be determined by type and quantity.
Payment Terms :
T/T; L/C.
Delivery Time :
Ex-work 3 days~ 1 week depends on quantity.
Packaging Details :
Seaworthy package/ Customer specified.
Description

Power Supply Surge Protective Device

​Product introduction:

SDZ100-50 is class 1 switch-type surge protection. It can effectively release the incoming and inductive lightning on the low-voltage line of system, and effectively protect power supply equipment from lightning strike.
Characteristic:
1/ Impulse current reaches 10/350μs 60kA;
2/ Low voltage limitation;
3/ Nominal discharge current reaches 8/20μs 200kA;
4/ Strong capability to cut off residual current;
5/ Discharge monitor is applicable to configurate with RS485 communication.

Installation:

1/ Install on 35mm rail;

2/ It is necessary to series connect a fuse or air switch with SPD.

Maintenance:
SPD should be inspectied and maintenance in reuglar basis, pls duly replace SPD if it is red color in display window.

Standard Technical Data:
A: Class Ⅰ
Class Ⅰ
Type SDZ100-50/420 SDZ100-50/440
Max. continuous operation voltage (Uc) 420V 440V
Protection voltage Up ＜2.5kV ＜2.5kV
Power Supply 3 phase/ Wind power system 3 phase/ Wind power system
Nominal discharge current, In (8/20μs) 200kA/phase 200kA/phase
Impulse discharge current, limp (10/350μs) 60kA/phase 60kA/phase
Cross section of connection wire 16mm2~30mm2 (Mul.) 16mm2~30mm2 (Mul.)
Protection mode L-PE; L-N; N-PE L-PE; L-N; N-PE
Environment condition -40℃~+85℃ -40℃~+85℃
Dimension (mm) 150*35(n)*78 (n is quanity) 150*35(n)*78 (n is quanity)
Installation 35mm std. rail 35mm std. rail

Class 1 Switch Type Power Surge Protective Device SDZ100-50Class 1 Switch Type Power Surge Protective Device SDZ100-50

Class 1 Switch Type Power Surge Protective Device SDZ100-50

Class 1 Switch Type Power Surge Protective Device SDZ100-50
