Chile Project Mobile Prefabricated Houses Light Steel Stud Modern Modular Design
Chile Project Mobile Prefabricated Houses Light Steel Stud Modern Modular Design
Chile Project Mobile Prefabricated Houses Light Steel Stud Modern Modular Design
Chile Project Mobile Prefabricated Houses Light Steel Stud Modern Modular Design
Chile Project Mobile Prefabricated Houses Light Steel Stud Modern Modular Design
Chile Project Mobile Prefabricated Houses Light Steel Stud Modern Modular Design
Chile Project Mobile Prefabricated Houses Light Steel Stud Modern Modular Design
Chile Project Mobile Prefabricated Houses Light Steel Stud Modern Modular Design
Specifications
Brand Name :
Sussman
Model Number :
SU-LG16
Certification :
CE; ISO
Place of Origin :
China
MOQ :
50 square meters
Price :
USD180-USD250 per square meter
Supply Ability :
500 square meter per week
Packaging Details :
plastic film
Name :
Prefabricated Light Steel Frame House / Luxury Prefab Villa
Steel Frame House :
steel structure + sandwich panel
Wall system :
cement board+glass wool+gypsum board
Insulation System :
90/100mm glass wool, XPS Panel
Roof :
EPS sandwich panel+glass wool, glaze tile
Wind loading :
<35m/s
Description

Chile Project Light Steel Stud Modern Modular Prefab House Design Modular Prefab House

The light steel structure villa is a building with external wall board and internal wall board insulation blocks, The light steel villa is composed of a structural system, a ground system, a floor system, a wall system and a roof system. Each system is composed of several unit modules, which are manufactured in the factory, and assembled by unit modules on the site.Light steel villa cold rolled hot galvanized or galvanized thin wall steel as the main load bearing structure, combined with thermal insulation, sound insulation, waterproof, fire protection and other maintenance materials, to build a functional diversity, energy-saving and environmental protection of the building.Its housing components can all be produced on a large scale in the factory, and only assembly operations are needed on the site, which realizes the factory prefabrication of components and on-site assembly construction of houses. It is a mature integrated housing system at present, and also the development direction of future housing construction.

Part Name Specification
Steel Structure System Cold-formed thin wall steel/Q550 0.8-1.5mm thickness
Wall System Decoration Panel Metal or PVC decoration panel
XPS panel(Grade B1) 1220*600*40mm
Moistureproof paper 50m2/coil
OSB board

6mm/9mm/12mm/15mm, conform to EU

EN300 standard.
Inner wall-- interior gypsum board 1220*2440*9mm
Roof System Roof Tile Asphalt tile/Resin tile+SBS+OSB+Glass Wool
Insulation System Wall,roof ,floor and ceiling 90/100mm glass wool, XPS Panel
Doors & Windows Entry door Steel security door, can be customized
Interior door Composite door, can be customized
Aluminum alloy door Glass sliding door, can be customized
Window

Plastic steel or Aluminum Alloy Window,

double- layer glass
Ceiling System Gypsum Panel + insulation cotton 90/100mm glass wool

Applications

1. Residence

2. Tourist and holiday house

3. Family house

4. Government residential project

5. Real estate development project

6. Constructions for other purpose
