Specifications
Brand Name :
CoreShine
Model Number :
CFL-1545-X1X2-X3WH
Certification :
UL, LVD, CE, ENEC, TUV, SAA, C-TICK, CB, GS, VDE, ETL
Place of Origin :
Guangdong, China
MOQ :
1 piece
Price :
Negotiable
Payment Terms :
L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :
25000-30000 pcs/month
Delivery Time :
5-8 working days
Packaging Details :
one set in one box (1678*170*92mm)
Item :
45w Led Linear Warehouse Lighting Solutions
Material :
Aluminum Alloy + PMMA lens/PC cover
Length :
1500mm
Power :
45W
CCT :
3000K/4000K/5000K/6000K
Dimming :
DALI, 1-10V, DIMswitch
Color :
White, Black, Silver
IP Rating :
IP20/IP54
Description

Smart Control Linear Trunking System | Led Warehouse Lighting with Motion Sensor

Surface Mounted Factory Led Linear Warehouse Lighting System 1500mm 45w

LED linear light is exclusively designed for designers and architects with imagination and personal style.LED linear light adopt premium aluminum profile, different dimension, and size, easy to install.2 types of installations method: suspended type, and embedded type, and different customized dimensions are also acceptable, which can meet install location requirements of different fields and occasions.

If you have any questions and suggestions, please feel free to contact us via email, we will give you a satisfactory reply within 24 hours.

  • FEATURES
  1. 【Economical】Save 85% on electricity bill of lighting.
  2. 【Long life】Quality and well made, last over 50,000 hours, reduce lights replacing frequency.
  3. 【Eye-protective design】Adopting the plastic white lampshade and qualified LED chips, it lights uniformly without flicker and protects your eyes from harsh and glaring lights.
  4. 【Safe and environmental】safe, green, durable, no mercury and hazardous substance contained.

  • DETAILS
Item: Led Linear Light Trunking System
Style: S-Line Material: Aluminum Alloy + PMMA lens / PC cover
Length: 1200mm, 1500mm, 2400mm, 3000mm Light Source: Smd2835 (Everlight/Samsung)
Trunking: 600mm, 1200mm, 1500mm, 2400mm, 3000mm Input Voltage: AC220-240VAC/100-277VAC
UGR: <19 CRI (Ra>): 80/95
Beam Angle: 25°;60°;90°;120°; Asymmetric; Double Asymmetric CCT: 3000K/4000K/5000K/6000K
PF: >0.95 THD: <15%
Lumen: 4800lm-19800lm Dimming: DALI, 1-10V, DIMswitch
Driver: Coreshine/Rubycon Color: White, Black, Silver
IP Rating: IP20 Light Color: Warm White, White, Cold White
Efficiency: 160lm/w Power: 35W,50W,65W,70W,100W,150W...
Warranty: 5 years Lifespan: 50000 hours
Installation Chain, Cord, Rod, Surface Mounted Connector L/T/X Node Connector can be choose
Function Dimmable (DALI/1-10V), Emergency, Sensor, Track Spot Light
Switch Type: Motion Sensor Switch Shipping: DHL/UPS/FEDEX/TNT...
Applications: Supermarket, Warehouse, Office, Stores, Shops, Commercial and Industrial Projects...

  • APPLICATIONS
Suitable for Supermarket, Warehouse, Workshop, Office, Car Parking, Schools, Classroom, Colleges, Hotels, Conference Rooms, Factories, Commercial Purposes, Industrial Projects, Institution Buildings, Universities, Hospitals, and other Architectural places that need energy saving and high color rendering index lighting.

CB LED Linear Trunking System , 45Watt Warehouse Pendant Light

  • Returns of Investment COMPARISON

We did a comparison test between Coreshine S-line and LED tube in the 300m² of warehouse

300 sq.m
Unite S-Line LED Tube
Lighting Effect lm/w 160 100
Qty of Luminaire set 600 960
Total Power Consumption KW 30 48
Unite Price of Electric CNY/KWH 1.5
Light Time Hour/Day 1.2
Electric bill/day CNY 540.00 864.00
Electric bill/month CNY 16,200.00 25,920.00
Electric bill/year CNY 194,400.00 311,040.00
Save the cost per year CNY 116,640.00

  • FAQ

Q1. Can I have a sample order for the led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What about the lead time?
A: Sample needs 5-10 days, mass production time needs 3-4 weeks for order quantity more than 1000pcs
Q3. Do you have any MOQ limit for the led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx, or TNT. It usually takes 5-7 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed with an order for led light?
A: Firstly let us know your requirements or application.
Secondly, We quote according to your requirements or our suggestions.
Thirdly customer confirms the samples and places a deposit for formal order.
Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. only available for mass order.
Q7: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.3%.
Secondly, during the guarantee period, we will send new lights with a new order for small quantities. For defective batch products, we will repair them and resend them to you or we can discuss the solution including re-call according to the real situation.

  • OUR ADVANTAGES
  • 5 years warranty
  • Toolless installation
  • Brand Components
  • Heat radiating area 106cm²/w
  • Longer warranty, Less maintenance
  • Rigorous technical
  • Quick connector
  • Electrical safety design
  • Organized wiring
  • Modularity, integration structure
