High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device
High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device
High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device
High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device
High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device
High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device
High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device
High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device
High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device
High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device
Specifications
Model Number :
LYFFM
Certification :
CE
Place of Origin :
China(Thailand available soon)
MOQ :
1 pc
Price :
20,000-50,000 USD per piece
Payment Terms :
T/T, Western Union, MoneyGram
Supply Ability :
5 pcs per Month
Delivery Time :
30-180 work days normally
Packaging Details :
carton, wood carton, pallets
Name :
Filling and Capping Machine
Application :
Pharmaceutical, Medical, bio-health, cosmetic
User :
pharmaceutical plants, health products facilities, cosmetics factories, and food production facotires
Filling Liquid Variety :
Oral Liquid, Liquid, Water
Pump :
Piston Pump, Ceramic Pump
Function :
filling, capping
Applicable Bottles Material :
Plastic, Glass Round Bottles
Availavle Bottle Volume :
10-100ml
Caps Variety :
Plastic, Alu Caps
Processing Standard :
GMP
Control System :
PLC
Touch Screen :
SIEMENS
Description

High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device

Complete machine description:
This machine is suitable for the filling of 10-100mL glass or PET bottles or plastic sprays, and the work of pump heads and rotary (rolling) covers. lt is widely used in medicine, daily chemical and other industries. lt adapts to a wide range of specifications, is easy to adjust, and has accurate positioning.It has no filling without bottle, no lid without bottle function, simple operation and stable operation. it can produce single machine and link production equipment. The SS 316L piston pump or peristaltic pump is used for filling, and the siphon needle is used for the needle, which can solve the problem that the needled rips and hangs liquid. The filling accuracy is high and easy to adjust, and it is easy to dismantle,clean and disinfect. The constant torgue and automatic slipping device are used to ensure that the bottle does not rotate and protect the bottle cap from abrasion, which meets the GMP specification requirements. Filling nozzles with follow up device can make sure the high speed working of machine.

High Speed Filling and Capping Machine With Follow Up Device:

Bottle Spec 10-100 ml glass or plastic bottles(need to change parts for different bottles)
Production Capacity 100-300 bottles/min(need to change mold for differnt size)
Filling nozzle Qty. 12
Capping Head Qty. 12
PASS Rate of hanging caps >99%
PASS Rate of capping >99%
Air Consumption and Pressure 03-0.6 Mpa / 5-10 cbm/h
Filling Accuracy < +/- 1%
Weight 1000Kg
Total Power about 4.5KW 380V 50Hz
Size 3600mm L x 1560mm W x 1780mm H

High Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up DeviceHigh Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up DeviceHigh Speed Filling And Capping Machine For Oral Liquid Glass Vials And PET Bottles With Follow Up Device

Performance characteristics:


1.The machine has reasonable and compact structure, stable operation, simplespecification adjustment and operation, and convenient maintenance.

2. the filling needle is specially treated to ensure no leakage and foaming, and the fillingvolume is higher accurate and stable.

3. the equipment is equipped with the functions of no filing without bottle and no cappingwithout bottle.
4. the needle carriage is driven by servo motor, with convenient stroke adjustment andstable andreliable oneration

After Sales Service:

1. Packing: Export packing standard

2. Shipment:

  • -Lead time: within 60-120 days after got the deposit and sign the drawings.
  • -Port of Loading: Shanghai

3. Support:

  • -Technical Support: Lingyao company provide machine operational training for 1-3 workers within 1-2 months after machine assembling in client’s plant. Client pay for 1200RMB/person/day, and provide food and hotel for living.
  • -Warranty: Within 3 years, the seller offers free spare parts delivered by courier.
