Specifications
Brand Name :
Lingyao
Model Number :
LYKFG2-30F
Certification :
CE, ISO, GMP
Place of Origin :
China(Thailand available soon)
MOQ :
1 unit
Price :
150,000-400,000USD per piece
Payment Terms :
D/A,D/P,T/T,Western Union,MoneyGram
Supply Ability :
4 pc per 6 months
Delivery Time :
180 work days
Packaging Details :
carton, wood carton, pallets
Machine Name :
Powder Filling Machine
Filling Material Type :
Dry Powder
Availavle Vials :
5-30ml(customizable)
Output Capacity :
30-50 BPM
Vials Material :
Glass
Breakage Rate :
<0.5%
Material Compatibility :
SS316
After-sales Service & Technical Support :
2 years guarantee maintenance, free spare parts available, and troubleshooting assistance to minimize downtime
Plugging Style :
Full
LAF System :
ISO Class 5(Optional)
Description

Pharmaceutical Powder Filling Machine for 10ml Vials, GMP Compliant Precision Dosing with Infrared Contamination Detection

Engineered for High-Precision, Low-Contamination Lyophilized Powder Processing

Key Differentiators vs. Market Alternatives
✅ AI-Driven Gravimetric Filling

  • Achieves ±1% dosing accuracy (0.5-3g range) through self-calibrating load cells, outperforming traditional volumetric systems prone to powder density variations.
  • Patented anti-caking vibration module ensures consistent flow for hygroscopic APIs like peptide/protein powders.

✅ Closed-Loop Sterility Assurance

  • Integrated infrared particulate detection scans vial interiors pre-filling (≤50μm sensitivity), reducing rejected batches by 30% compared to manual sampling.
  • HEPA-filtered laminar airflow (ISO Class 5) maintains GMP-grade aseptic conditions during stopper placement.

✅ Modular Scalability

  • Rapid changeover between R&D batches (30 vials/min) and commercial production (50 vials/min) via programmable PLC interfaces.
  • Compatible with lyophilizer integration for end-to-end freeze-dried injectable workflows.

Technical Parameters

Feature Specification
Vial Capacity 10ml (2R-20mm neck type)
Powder Range 0.5g - 3g (±1% accuracy)
Speed 30-50 vials/min (adjustable)
Residual Moisture Control ≤0.5% post-filling (via dry N₂ purge)
Detection System Dual IR cameras + weight check
Compliance cGMP, FDA 21 CFR Part 211/820
Customization Available for 5ml-30ml vial formats

Pharmaceutical Powder Filling Machine for 10ml Vials, GMP Compliant Precision Dosing with Infrared Contamination Detection

Pharmaceutical Powder Filling Machine for 10ml Vials, GMP Compliant Precision Dosing with Infrared Contamination Detection

Pharmaceutical Powder Filling Machine for 10ml Vials, GMP Compliant Precision Dosing with Infrared Contamination Detection

Why Choose LINGYAO?

  • Pharma-First Design: 15+ years specializing in powder handling systems for lyophilized products.
  • Lifecycle Support: On-site IQ/OQ/PQ validation packages and spare parts inventory in EU/NA warehouses.
  • Sustainability Edge: 40% lower nitrogen consumption than industry average through optimized purge algorithms.
