0875-1X1T-B2 100/1000 Base-T 1 Port RJ45 Magjack Tab Up Orange&Green/Yellow Led
0875-1X1T-B2 100/1000 Base-T 1 Port RJ45 Magjack Tab Up Orange&Green/Yellow Led
0875-1X1T-B2 100/1000 Base-T 1 Port RJ45 Magjack Tab Up Orange&Green/Yellow Led
0875-1X1T-B2 100/1000 Base-T 1 Port RJ45 Magjack Tab Up Orange&Green/Yellow Led
0875-1X1T-B2 100/1000 Base-T 1 Port RJ45 Magjack Tab Up Orange&Green/Yellow Led
0875-1X1T-B2 100/1000 Base-T 1 Port RJ45 Magjack Tab Up Orange&Green/Yellow Led
Specifications
Brand Name :
LINK-PP
Model Number :
0875-1X1T-B2
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
Guangdong,China
Compatible :
Belfuse
Competitor P/N :
0875-1X1T-B2
Manufacturer :
LINK-PP
Compatible Brands :
Belfuse
Application - LAN :
ETHERNET (NON PoE)
Temperature :
0℃ to 70℃
Latch :
Up
Pin Type :
THT SOLDER
LED Option :
Orange&Green / Yellow
Shield EMI Tabs :
YES
Reviews :
67
N.W/pcs :
0.008kg
Package :
Tray
SPQ :
50pcs
Qty/carton :
1200pcs
Carton size :
32*30*31cm
G.W/carton :
9kg
Description

Belfuse 0875-1X1T-B2 Compatible LINK-PP 100/1000 Base-T RJ45 Magjack for Digital Camera and Fieldbus System (Single Port, Tab Up, Orange&Green/Yellow Led)


The 0875-1X1T-B2 supports speed 100/1000 Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Digital Camera, Router, Automation and Network Firewall.


LINK-PP Part Number:
 LPJGxxxxxx
 Belfuse Part Number 0875-1X1T-B2
Part Status
 Active Connector Type
 Jack
Number of Positions/Contacts
 12p8c (RJ45, Ethernet) Application-Lan
 Ethernet( NON PoE )
Number of Ports
1x1 PortSpeed
10/100/1000 Base-T
Latch
UPCores per Port
8
Orientation
90° Angle (Right)PCB Mount Angle

SIDE ENTRY

Shield EMI Tabs
WithLED Option

Orange&Green/Yellow

PCB
FR4Temperature

0℃ TO 70℃

Bst Circuit
YesAutomDX

YES

Diodes
NoContact Mating Area Plating

GOLD 6u"/15u"/30u"

Turns Ratio RX/TX
1CT:1CTConfiguration RX/TX

T,C
