LP7038ANL 10G Base-T SMD Lan Transformer Modules Single Port 24 PIN
LP7038ANL 10G Base-T SMD Lan Transformer Modules Single Port 24 PIN
Specifications
Brand Name :
LINK-PP
Model Number :
LP7038ANL
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
Guangdong,China
LINK-PP P/N :
LP7038ANL
Manufacturer :
LINK-PP
Compatible Brands :
LINK-PP
Mounting Type :
SMT
Temperature :
-40℃ TO +85℃
Application - LAN :
ETHERNET(NOT PoE)
Reviews :
30
Description

LINK-PP LP7038ANL SMD Lan Transformer Modules For Digital Camera (SMD,24PIN,Single Port )


The LP7038ANL speed 10G Base-T, It is compliant to IEEE 802.3, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to Router, Set-top Box, SMPS, Digital Camera.


LINK-PP Part Number:
 LP7038ANL Transformer Type
 Lan Transformer
Part Status
 Active Turns Ratio - Primary:Secondary
 1:1 Transmitter, 1:1 Receiver
Construction
 OPEN FRAME
 Application-Lan
 Ethernet(NON PoE)
Number of Ports
SINGLESpeed
10G Base-T
Package
Tape & ReelCores per Port
8
AutomDX
YesComment

SAME AS NL VERSION

PIN number
24
Mounting Type

Surface Mount

Package Height (Inches/mm)
0.268/6.80
Package Length (Inches/mm)0.691/17.55
Package Width (Inches/mm)
0.480/12.20
Temperature
-40℃ TO +85℃
Turns Ratio RX/TX
1CT:1CT
Configuration RX/TX
T,C,S
