Pulse HX1333NL Compatible LINK-PP LP1333NL 100 Base-T High Isolation 4.5KVrms Single Port 12 Pin Ethernet Transformer
Pulse HX1333NL Compatible LINK-PP LP1333NL 100 Base-T High Isolation 4.5KVrms Single Port 12 Pin Ethernet Transformer
Specifications
Brand Name :
LINK-PP
Model Number :
LP1333NL
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
Guangdong,China
Compatible :
Pulse
Competitor P/N :
HX1333NL
Questions :
1
Reviews :
10
N.W/pcs :
0.005kg
Package :
Reel
SPQ :
350pcs
Qty/carton :
1400pcs
Carton size :
37*37*25cm
G.W/carton :
7kg
Description

Pulse HX1333NL Compatible LINK-PP LP1333NL 10/100 Base-T Telecom Lan Transformer For Industrial PC (High Isolation,4.5KVrms,POE, 12 PIN,Single Port )


The LP1333NL supports speed 10/100 Base-T, It is compliant to IEEE 802.3 af, UL, Reach, RoHs, ISO19001,ISO14001 standards.It can be used to support application, such as Digital Camera, Router, Automation and Industrial PC.


LINK-PP Part Number:
 LP1333NL Pulse Part Number HX1333NL
Part Status
 Active Transformer Type
 Lan Transformer
Construction
 OPEN FRAME
 Application-Lan
 Ethernet(PoE)
Number of Ports
Single PortSpeed
10/100 Base-T High Isolation
Package
Tape & ReelCores per Port
2
AutomDX
YesHi-POT RATING
4.5KVrms
PIN number
12Mounting Type

Surface Mount

Package Height (Inches/mm)
0.340/8.65Package Length (Inches/mm)0.673/17.10
Package Width (Inches/mm)
0.581/14.75Temperature
-40℃ TO +85℃
Turns Ratio RX/TX
1CT:1CT
Configuration RX/TX
T,C,S
