TE 2170805-4 QSFP28 Cage Ganged (1 x 2) Connector 28 Gb/s Through Hole
TE 2170805-4 QSFP28 Cage Ganged (1 x 2) Connector 28 Gb/s Through Hole
TE 2170805-4 QSFP28 Cage Ganged (1 x 2) Connector 28 Gb/s Through Hole
TE 2170805-4 QSFP28 Cage Ganged (1 x 2) Connector 28 Gb/s Through Hole
Specifications
Brand Name :
LINK-PP
Model Number :
2170805-4
Certification :
UL,ROHS,Reach,ISO
Place of Origin :
Guangdong,China
Compatible :
TE
Competitor P/N :
2170805-4
Manufacturer :
LINK-PP
Pluggable I/O Product Type :
Cage
Data Rate (Max) (Gb/s) :
28
EMI Containment Feature Type :
Internal/External EMI Springs
Lightpipe Options :
Not Optional
Termination Method to Printed Circuit Board :
Through Hole - Press-Fit
Operating Temperature Range (°C) :
-40 – 85
Description

QSFP28, Cage, 1 x 2, Internal/External EMI Springs, Standard, Data Rate (Max) 28 Gb/s, 2 Port, zQSFP+/QSFP28

Part Number:
 2170805-4 Part Status
 Active
Connector Style
 Cage, Ganged (1 x 2)Connector Type
 QSFP28
Number of Positions
-Mounting Type
Through Hole, Right Angle
Termination
Press-FitFeatures
EMI Shielded

Port Matrix Configuration
1x2 PortsNumber of Ports
2
Number of Rear EONs per Port Column
1Data Rate (Max)(Gb/s)
28
Operating Temperature Range
-40 – 85°C
Pluggable I/O Applications
SFP+ Stacked Belly-to-Belly
Circuit Application
SignalEMI Containment Feature Type
Internal/External EMI Springs

Included Lightpipe
NoCage MaterialNickel Silver

PCB Thickness (Recommended)
1.57mm[.062in]Tail Length
2.05mm[.081in]
